| Westerschelde 24 April 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 27/04/17 | Westerschelde 27/04/17 | Westerschelde 27/04/17 | Westerschelde 11/02/12 | Westerschelde 18/07/14 | Westerschelde 28/02/20 | |||||
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 11/02/12 | Westerschelde 11/02/12 | Westerschelde 06/03/12 | Westerschelde 06/03/12 | Antwerpen 29/03/14 | Antwerpen 29/03/14 | |||||
|
Name |
BRO ANNA |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9344435 |
|
Call sign |
9V3609 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flag |
02/2008 - 10/2015 The Netherlands, Delfzijl - Call sign: PHNF |
|
GT |
12.164 t |
|
DWT |
Summer: 16.979 t |
|
NT |
5.489 t |
|
Length |
144,05 m overall 133,80 m between perpendiculars |
|
Breadth |
23,03 m extreme |
|
Draught |
Max: 9,00 m |
|
Keel to mast end |
43,40 m |
|
Freeboard |
3.411 mm |
|
Depth |
12,40 m moulded |
|
Speed |
14,0 knots |
|
Built |
2008 |
|
Keel laid |
23/05/2006 |
|
Launch date |
28/04/2007 |
|
Date of completion |
14/02/2008 |
|
Builder |
Tuzla Gemi Endustrisi A.S. Tersaneler Caddesi No 6 34944 Tuzla - Istanbul Turkey |
|
Yard number |
030 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke single acting 6 cylinder 480 x 600 mm combustion engine Mcr 6.900 kW at 500 rpm Manufacturer: MAN-B&W Diesel A.G., Augsburg - Germany |
|
Propellers |
1x MAN-B&W VBS 1460 controllable pitch propeller |
|
Boilers |
Auxiliary boiler, vertical shell type (Oil-fired) - 9,0 bar Auxiliary boiler, composite (Exhaust / Oil-fired) - 12,0 bar Builder: Garioni Naval, Castelmella - Italy |
|
Shaft generator |
1x AVK DSU 86M1-4 - 1.500 kW |
|
Generators |
3x Caterpillar 3508 DITA diesel engines each 968 kW connected with Leroy Somer generator each 850 kW |
|
Emergency generator |
1x MAN D2866 TE diesel generatorset Builder: MAN Truck & Bus AG - GE Motoren-Nürnberg - Germany |
|
Number of cargo tanks |
12 tanks + Slop tank |
|
Number of segregations |
12 |
|
Cargo tank capacity |
19.852 m³ |
|
Slop tank capacity |
260 m³ |
|
Number of pumps |
12x Ramo cargo pumps each 385 m³/h |
|
Cargo pumping capacity |
1.800 m³/h |
|
Tank capacities 100% |
Heavy Fuel oil: 625,2 m³ Diesel oil: 109,0 m³ Fresh water: 502,0 m³ Hydraulic oil: 18,9 m³ Lube oil: 81,0 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 10,0 t 1x Engine room crane 1x Provision crane - SWL 3,0 t |
|
Commerical manager |
Maersk Tankers Singapore Pte. 15-01, Robinson Point, 39, Robinson Road Singapore 068911 Republic of Singapore |
|
ISM manager |
Maersk Tankers A/S Holmbladsgade 133 2300 Copenhagen, DK Denmark |
|
Previous managers |
2008 - 2010 Broström Tankers Sweden AB / Marin Ship Management B.V. (Delfzijl), Gothenburg - Sweden 2010 - 2015 Broström Tankers Ltd., Gothenburg - Sweden |
|
Registered owner |
Maersk Tankers Singapore Pte. 15-01, Robinson Point, 39, Robinson Road Singapore 068911 Republic of Singapore |
|
Previous owners |
2008 - 2015 Bro A B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
26 February 2023 |
