| Vlissingen 11 November 2018 |
|
Name |
SOMTRANS XX |
|
Type |
Chemical tanker, Inland waterways |
|
IMO Number |
9571234 |
|
ENI-number |
02333399 |
|
Call sign |
PB8110 |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
Previous flags |
Belgium, Antwerpen |
|
Tonnage |
4.296 t |
|
Length |
135,00 m overall |
|
Breadth |
11,45 m extreme |
|
Draught |
3,80 m |
|
Depth |
4,16 m |
|
Speed |
Max: 14,3 knots |
|
Built |
2010 |
|
Keel laid |
29/12/2008 |
|
Date of completion |
10/2010 |
|
Builder casco |
Sainty Shipbuilding (Jiangdu) China Yard number: 07STIG066 |
|
Builder completion |
Den Breejen Shipyard Hardinxveld-Giessendam The Netherlands Yard number: 3521 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar 3508 (C) DI-TA electronic combustion engines each 783 kW / 1.065 kW at 1.600 rpm |
|
Gearbox |
2x Masson Marine MM W5200 - reduction 4.962:1 |
|
Propellers |
2x Propellers with Giessen Optima nozzles diameter 1.714 mm |
|
Generators |
1x Caterpillar C32 Acert diesel engine 750 hp at 1.800 rpm connected with Stamford HCM534F2 generator |
|
Bow thruster |
Verhaar Omega-Jet - 580 hp / 426 kW electric motor at 1.780 rpm |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity 100% |
5.178 m³ |
|
Number of pumps |
14x Marflex MDPE-80 cargo pumps each 80,0 m³/h equipped with 35 kW electric motors - total capacity 1.120 m³/h 14x MarFlex air-driven suction pumps 1x Marflex MBDPC-200 ballast pump 650 m³/h |
|
Lifting equipment |
1x car crane - SWL 1.750 kg |
|
Owner |
Somtrans NV Albertkanaalbaan 9 2110 Wijnegem Belgium |
|
Latest data adjustment |
09 January 2024 |
