| Westerschelde 20 April 2017 |
 |
|
| Westerschelde 20/04/17 | |
|
Name |
MINERVA ARIES |
|
Previous names |
2008 - 2012 Libyan Galaxy |
|
Type |
Crude oil tanker - Aframax |
|
IMO-number |
9412177 |
|
Call sign |
5LGB8 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2008 - 2012 Republic of Panama, Panama City - Call sign: 3FOO8 2012 - 2022 Malta, Valletta - Call sign: 9HA3063 |
|
GT |
57.135 t |
|
DWT |
105.4836,5 t |
|
NT |
33.181 t |
|
Displacement |
123.916 t |
|
Length |
243,98 m overall 234,00 m between perpendiculars |
|
Breadth |
42,00 m moulded |
|
Draught |
Summer: 15,02 m |
|
Freeboard |
6.016 mm |
|
Depth |
21,00 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2008 |
|
Keel laid |
23/06/2008 |
|
Launch date |
22/09/2008 |
|
Delivery date |
28/11/2008 |
|
Builder |
Hyundai Heavy Ind. Co., Ltd. 1, Cheonha-Dong Dong-Ku Ulsan South Korea |
|
Yard number |
1991 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hyundai/MAN-B&W 6C60MC-C - 6 cylinder 600 x2.400 mm combustion engine Mcr 13.560 kW / 18.184 bhp at 105,0 rpm |
|
Propellers |
1x Solid four bladed propeller Manufacturer: HHI Engine&Machinery Division |
|
Boilers |
2x Auxiliary boiler - 19,0 MPa 1x Exhaust gas boiler Manufacturer: Kangrim Heavy Ind. Co.,Ltd. |
|
Generators |
3x Main diesel generatorsets each 710 kW Manufacturer: HHI Electro Electric Systems |
|
Number of tanks |
14 |
|
Cargo tank capacity 98% |
115.745,60 m³ excluding slop tanks |
|
Slop tank capacity 98% |
2.453,40 m³ |
|
Number of pumps |
3x Cargo pumps each 3.000 m³/h |
|
Tank capacities |
Lub oil: 177,90 m³ Fuel oil: 3.081,30 m³ Diesel oil: 233,90 m³ Ballast: 37.928,60 m³ Fresh water: 373,60 m³ |
|
Lifting equipment |
1x Engine room overhead crane - SWL 4,0 t Manufacturer: Dongnam Marine Co., Ltd. 1x Hose handling crane Port - SWL 15,0 t 1x Hose handling crane STBD - SWL 15,0 t 1x Provision crane Port - SWL 2,0 t Manufacturer: Oriental Precision Engineering Co., Ltd. |
|
Crew size |
30 |
|
Manager |
Minerva Marine Inc. 141-143 Vouliagmenis Avenue Voula, Athens, 16673 Greece |
|
Registered owner |
Flutura Holdings Co. |
|
Previous names & owners |
2008 - 2012 Libyan Galaxy - Queen Marine Inc. (Pioneer Ship Management Services) |
|
Latest data adjustment |
30 April 2023 |
