| Westerschelde 24 April 2018 |
 |
 |
|
| Westerschelde 24/04/18 | Westerschelde 24/04/18 | |
|
Name |
SCOT FRANKFURT |
|
Previous names |
2005 - 2015 Wappen Von Frankfort |
|
Type |
Chemical tanker |
|
IMO-number |
9274537 |
|
Call sign |
9HA4094 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2005 - 2010 United Kingdom - Call sign: MKUW3 2010 - 2015 Liberia, Monrovia - Call sign: A8XB9 |
|
GT |
5.145 t |
|
DWT |
8.182 t |
|
NT |
2.532 t |
|
Length |
116,90 m overall 110,40 m between perpendiculars |
|
Breadth |
18,00 m moulded 18,20 m extreme |
|
Draught |
Summer: 7,41 m |
|
Depth |
9,40 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2005 |
|
Keel laid |
29/06/2004 |
|
Date of completion |
30/11/2005 |
|
Builder |
Santierul Naval Damen Galati S.A. Romania |
|
Yard number |
1059 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
2x MAN-B&W 6L27/38 - 6 cylinder combustion engine each 1.800 kW / 2.445 bhp |
|
Propellers |
2x Pitch propellers |
|
Boilers |
2x Exhaust boiler Alpha Laval CHR Heating surface: 60 m² 1x Auxiliary boiler Alpha Laval CHO Heating surface: 39 m² |
|
Shaft generator |
2x each 492 kW |
|
Generators |
2x Main diesel generatorsets each 387 kW |
|
Emergency & harbour gen. |
1x Diesel generatorset 387 kW |
|
Bow thruster |
1x 400 kW |
|
Number of cargo tanks |
14 + 2 slop tanks |
|
Cargo tank capacity |
8.857 m³ |
|
number of pumps |
14x Framo cargo pumps each 200 m³/h 2x Framo cargo pumps each 300 m³/h |
|
Tank capacities |
Fuel oil: 513 m³ Fresh water: 257 m³ |
|
Manager |
Scot Gemi Isletmeciligi AS Kadikoy, Istanbul Turkey |
|
Registered owner |
Scot Frankfurt SA Daire 5 Cam Fistigi Sokak 305/A,Caddebostan Mah Kadikoy 34398 Istanbul Turkey |
|
Previous names & owners |
2005 - 2015 Wappen Von Frankfort - Schiffahrtsgesellschaft Wappen Von Frankfurt mbH Co., KG |
|
Latest data adjustment |
09 April 2023 |
