| Westerschelde 07 March 2019 |
|
Name |
FMT GUMULDUR |
|
Previous names |
2009 - 2009 Olympos 2009 - 10/2017 Palchem 1 |
|
Type |
Oil and chemical carrier |
|
IMO-number |
9427976 |
|
Call sign |
9HA2097 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
8.995 t Suez: 9.402 t |
|
DWT |
10.996,9 t |
|
NT |
4.514 t Suez: 8.462 t |
|
Displacement |
15.536,1 t |
|
Length |
142,98 m overall 134,00 m between perpendiculars |
|
Breadth |
21,70 m moulded |
|
Draught |
Summer: 8,69 m |
|
Keel to mast end |
29,94 m |
|
Freeboard |
3.774 mm |
|
Depth |
11,10 m moulded |
|
Speed |
14,0 knots |
|
Built |
2009 |
|
Keel laid |
15/08/2007 |
|
Delivery date |
17/07/2009 |
|
Builder |
Celiktekne Tersanesi Tersaneler Bolgesi No. 12 Tuzla Turkey |
|
Yard number |
70 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 6S35MC - 2 stroke 6 cylinder 350 x 1.400 mm combustion engine 4.440 kW / 6.037 hp at 173,0 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x Auxiliary boilers NG-C4000 - 7,0 MPa each 1x Exhaust gas boiler NG-EG-962 - 7,0 MPa Manufacturer: Euroboilers Garioni Naval |
|
Shaft generator |
1x Leroy Somer generator 850 kW |
|
Generators |
3x CAT C-32 main diesel generatorsets each 715 kW |
|
Bow thruster |
1x 500 kW |
|
Number of tanks |
14 + 1 slop tank |
|
Cargo tank capacity 98% |
15.104,27 m³ |
|
Number of pumps |
14x Cargo pumps each 330 m³/h 1x Cargo pump 110 m³/h |
|
Tank capacities |
Fuel oil: 773,76 m³ Ballast: 5.562,19 m³ Lub oil: 40,08 m³ Diesel oil: 138,14 m³ Hydraulic oil: 4,82 m³ Fresh water: 333,85 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t 1x Provision crane - SWL 2,0 t |
|
Crew size |
21 |
|
Commercial manager |
United Maritime Logistics SA Rue du Rhone, 42 1204 Geneva Switzerland |
|
ISM manager |
Fleet Management Ltd. 27th Floor, South Island Place, 8, Wong Chuk Hang Road, Southern Hong Kong China |
|
Registered owner |
Gunesh Shipping Ltd., Malta Care of United Maritime Logistics (Switzerland) SA, Rue du Rhone, 42 1204 Geneva Switzerland |
|
Latest data adjustment |
08 November 2022 |
