| Westerschelde 03 March 2020 |
 |
| Westerschelde 03/03/20 |
|
Name |
NS ARCTIC |
|
Type |
Crude oil tanker |
|
IMO-number |
9413547 |
|
Call sign |
A8SA7 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
62.372 t |
|
DWT |
111.107 t |
|
NT |
33.595 t |
|
Displacement |
132.103 t |
|
Light weight |
20.996 t |
|
Length |
249,99 m overall 239,00 m between perpendiculars |
|
Breadth |
44,05 m extreme |
|
Draught |
Summer: 14,72 m |
|
Keel to mast end |
50,40 m |
|
Freeboard |
6.319 mm |
|
Depth |
21,00 m |
|
Speed |
Max: 15,4 knots |
|
Built |
2009 |
|
Keel laid |
09/12/2008 |
|
Launch date |
28/02/2009 |
|
Date of completion |
04/05/2009 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hyundai/MAN-B&W 7S60MC-C - 2 stroke 7 cylinder 600 x 2.292 mm combustion engine 14.280 kW / 19.415 hp at 105,0 rpm Build: 26/11/2008 Builder: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Exhaust boiler Aalborg Mission XW 2x Auxiliary boiler Aalborg Mission OL |
|
Generators |
3x Himsen 6H21/32 diesel generatorsets each 1.110 kW |
|
Emergency generator |
1x Cummins 6CTA-8.3-D(M) diesel generatorset 160 kW |
|
Number of tanks |
14 |
|
Cargo tank capacity |
Liquid: 123.641,2 m³ |
|
Number of pumps |
4x Cargo pumps each 2.000 m³/m³ |
|
Manager |
SUN Ship Management (D) Ltd./ Office OT 17-32, 17th Floor , Office Tower, Central Park Towers, Dubai International Financial Centre Dubai United Arab Emirates |
|
Registered owner |
NS Arctic Shipping Inc., Monrovia - Liberia Care of SCF Management Services (Dubai) Ltd , Office OT 17-32, 17th Floor, Office Tower, Central Park Towers, Dubai International Financial Centre Dubai United Arab Emirates |
|
Latest data adjustment |
16 September 2022 |
