| Vlissingen, The Netherlands 07 May 2017 |
 |
 |
|
| Vlissingen 07/05/17 | Westerschelde 10/05/17 | |
|
Name |
ASOPOS |
|
Type |
Crude oil tanker - Panamax |
|
IMO-number |
9309253 |
|
Call sign |
A8HS6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
35.711 t Suez: 37.205,78 t |
|
DWT |
Summer: 61.286 t Winter: 59.643 m |
|
NT |
16.707 t Panama: 29.627 t Suez: 33.156,78 t |
|
Displacement |
Summer: 72.605 t Winter: 70.962 t |
|
Length |
213,35 m overall 206,56 m between perpendiculars |
|
Breadth |
32,29 m extreme |
|
Draught |
Summer: 12,29 m Winter: 12,03 m |
|
Keel to mast end |
45,33 m |
|
Air draft |
Lightship: 43,17 m Normal ballast: 39,62 m At loaded summer deadweight: 33,04 m |
|
Freeboard |
Summer: 6.255 mm Winter: 6.510 mm |
|
Depth |
18,50 m moulded |
|
Speed |
Max: 14,8 knots |
|
Built |
2006 |
|
Keel laid |
24/12/2004 |
|
Date of completion |
09/06/2006 |
|
Builder |
Sumitomo Heavy Industries Marine & Engineering Co., Ltd. - Yokosuka Yard Japan |
|
Yard number |
1321 |
|
Hull material |
Steel - Part higher tensile steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsui/MAN-B&W 7S50MC - 2 stroke single acting 7 cylinder 500 x 1.910 mm combustion engine Mcr 10.010 kW / 13.610 hp at 127,0 rpm Builder: Mitsui Engineering & Shipbuilding C Ltd. - Japan |
|
Propellers |
1x Fixed pitch propeller - aft at 127,0 rpm |
|
Boilers |
1x Exhaust gas eEconomiser 1x Water tube auxiliary boiler |
|
Generators |
2x Cummins 5DK-20 - 4 stroke 6 cylinder 200 x 300 mm diesel engines each Mcr 610 kW connected with generators each 560 kW / 405 Volt 60 Hz |
|
Number of tanks |
12 |
|
Cargo tank capacity 98% |
64.006 m³ m³ excluding slop tanks |
|
Natural segregation 98% |
Seg#1: 24.612,0 m³ (1P-S, 4P-S) Seg#2: 24.067,6 m³ (2P-S, 5P-S) Seg#3: 21.499,4 m³ (3P-S, Slop P-S) |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
6.173 m³ |
|
Residual/Retention oil tanks capacity 98% |
400 m³ |
|
Manifolds |
Bow to centre manifold: 102,93 m Stern to centre manifold: 109,65 m Distance bridge front to centre of manifold: 77,98 m |
|
Number of pumps |
3x Vertical centrifugal cargo pumps each 2.000 m³/h 2x Ballast pump each 1.125 m³/h |
|
Tank capacities |
Fuel oil: 1.244 m³ MGO: 245 m³ Ballast: 26.080 m³ |
|
Lifting equipment |
Hose handling crane - SWL 15,0 t |
|
Crew size |
22 |
|
ISM & commercial manager |
Pleiades Shipping Agents SA 262, Kifisias Avenue, Kifisia 145 62 Athens Greece |
|
Registered owner |
Evelyn Shipping & Trading SA Care of Pleiades Shipping Agents SA 262, Kifisias Avenue, Kifisia 145 62 Athens Greece |
|
Latest data adjustment |
21 August 2022 |
