Name
|
BASTILLE STREET
|
|
Previous names
|
2011 - 2014 Pacific Sapphire
|
|
Type
|
Crude and oil products carrier - Panamax
|
|
IMO-number
|
9573701
|
|
Call sign
|
A8YZ6
|
|
Flag
|
Liberia
|
|
Port of registry
|
Monrovia
|
|
GRT
|
28.778 t
Suez: 30.242,07 t
|
|
DWT
|
47.906 t
|
|
NRT
|
12.680 t
Suez: 27.518,09 t
Panama: 23.899,73 t
|
|
Displacement
|
58.025 t
|
|
Length
|
179,99 m overall
|
|
Breadth
|
32,20 m moulded
|
|
Draught
|
Summer: 12,60 m
|
|
Moulded L x B x D
|
172,00 x 32,20 x 19,05 m
|
|
Registered L x B x D
|
172,47 x 32,20 x 19,05 m
|
|
Keel to mast end
|
44,99 m
|
|
Freeboard
|
Summer: 6.462 mm
|
|
Depth
|
19,05 m moulded
|
|
Speed
|
15,3 knots
|
|
Built
|
2011
|
|
Keel laid
|
02/09/2010
|
|
Launch date
|
14/01/2011
|
|
Date of completion
|
25/05/2011
|
|
Builder
|
Iwagi Zosen Co.,Ltd.
4690 Iwagi, Kamijima-Cho, Ochi-Gun, 794-2410
Japan
|
|
Yard number
|
S-Z294
|
|
Hull material
|
Steel
|
|
Hull type
|
Double hull
|
|
Main engine
|
1x Mitsui/MAN-B&W 6S50MC-C – 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW / 12.889 hp at 127,0 rpm
Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd.
|
|
Propeller shaft
|
1x Oil lubrication shaft without monitoring device
Diameter: 490 mm
|
|
Propellers
|
1x Fixed pitch propeller
|
|
Boilers
|
1x Fired boiler - 9MPa
1x Unfired exhaust gas boiler - 14 MPa
Manufacturer: Miura Co., Ltd.
|
|
Generators
|
3x Main diesel generatorsets each 900 kW
Manufacturer: Nishishiba Electric Co., Ltd.
|
|
Number of tanks
|
18
|
|
Cargo tank capacity 100%
|
Liquid: 54.902 m³
|
|
Number of pumps
|
4x Cargo pumps each 1.100 m³/h
|
|
Tank capacities
|
Fuel oil: 2.221,36 m³ m³
Fresh water: 532,50 m³
Lub oil: 20,55 m³
Diesel oil: 144,33 m³
Ballast: 20.845,97 m³
|
|
Lifting equipment
|
1x Provision crane - SWL 0,9 t
1x Provision crane - SWL 2,0 t
Manufacturer: Nantong Sekigahara Machinery Manufacturing Co., Ltd
1x Hose Handling Crane - SWL 10,0 t
Manufacturer: Kyoritsu Kikai Co., Ltd.
|
|
ISM & commercial manager
|
Zodiac Maritime Limited
5th Floor, Portman House, 2 Portman Street, London, W1H 6DU
United Kingdom
|
|
Registered owner
|
Tennent Star Navigation Inc.
|
|
Previous owner
|
Forward Gloria Navigation SA
Kyukan-Hakata Building, 26-29, Hakataekimae 3-chome, Hakata-ku, Fukuoka-shi, Fukuoka Prefecture, 812-0011
Japan
|
|
Latest data adjustment
|
01 April 2024
|
