Intermezzo - IMO 9804825

Name

INTERMEZZO

Type

Oil/Chemical/Molasses carrier

IMO-number

9804825

Call sign

9V5490

Flag

Republic of Singapore

Port of registry

Singapore City

GT

22.988 t

DWT

37.328,95 t

NT

9.866 t

Length

180,15 m overall

Breadth

28,20 m moulded

Draught

Summer: 11,37 m

Moulded L x B x D

174,15 x 28,20 x 16,30 m

Registered L x B x D

174,34 x 28,20 x 16,30 m

Keel to mast end

40,20 m

Freeboard

Summer: 4.964 mm

Depth

16,30 m moulded

Speed

Service: 14,6 knots

Max: 17,3 knots

Built

2019

Keel laid

25/11/2015

Launch date

22/03/2019

Date of completion

12/06/2019

Builder

Kitanihon Shipbuilding Co., Ltd.

Hachinohe

Japan

Yard number

657

Hull material

Steel

Hull type

Double hull

Main engine

1x MAN-B&W/Makita 6S46ME-B8 - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine 6.100 kW / 8.294 hp at 110,0 rpm

Manufacturer: Makita Corporation - Japan

Propeller shaft

1x Oil lubrication shaft with monitoring device

Diameter: 460 mm

Propellers

1x Fixed pitch propeller

Boilers

1x Auxiliary vertical boiler - 0,93 MPa

Evaporation: 18;98 t/h

Manufacturer: Tortoise Engineering Co., Ltd.

Generators

3x Main diesel generatorsets each 680 kW

Bow thruster

1x 868 kW

Number of tanks

28

Cargo tank capacity

Liquid: 39.266,42 m³

Number of pumps

10x Cargo pumps each 330 m³/h

18x Cargo pumps each 220 m³/h

Tank capacities

Fuel oil: 2.336,08 m³

Fresh water: 592,90 m³

Commerical manager

MOL Chemical Tankers Pte Ltd.

15-01, UIC Building, 5, Shenton Way

Singapore 068808

Republic of Singapore

ISM manager

TM Shipmanagement Co., Ltd.

8th Floor, Korea Seafarers' Center Building

66, Chungjang-daero 9beon-gil, Jung-gu

Busan

South Korea

Registered owner

FGL Pacific (Singapore) Pte. Ltd.

Care of MOL Chemical Tankers Pte Ltd.

15-01, UIC Building, 5, Shenton Way

Singapore 068808

Republic of Singapore

Latest data adjustment

04 December 2021
