Name |
ELBTRADER |
|
Type |
Cellular containership - Handysize |
|
IMO-number |
9388534 |
|
Call sign |
5BKJ4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
2008 - 2016 Antigua & Barbuda, St. John’s - Call sign: V2DW4 |
|
GT |
8.246 t |
|
DWT |
Summer: 11.174 t |
|
NT |
4.002 t |
|
Number of 20ft containers |
On deck: 756 In hold: 218 Total: 974 |
|
Container capacity 14t |
586 |
|
Reefer capacity |
170 |
|
Length |
139,60 m overall 133,25 m between perpendiculars |
|
Breadth |
22,39 m extreme 22,20 m moulded |
|
Draught |
Summer: 7,36 m |
|
Depth |
9,50 m |
|
Speed |
Max: 18,0 knots |
|
Built |
2008 |
|
Keel laid |
24/04/2008 |
|
Launch date |
28/08/2008 |
|
Date of completion |
19/12/2008 |
|
Builder |
Detlef Hegemann Rolandwerft GmbH & Co. KG Bremen Germany |
|
Yard number |
245 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M43C - 4 stroke single acting 9 cylinder 430 x 610 mm combustion engine 8.402 kW / 11.4213 hp at 500 rpm Manufacturer: Caterpillar Motoren GmbH & Co.KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 174 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 15,0 m² 1x Exhaust gas heated - 9,0 bar Heating surface: 172,0 m² |
|
Electric installations |
1x Plant 440/230 V - 1.092 kVA 1x Plant 440 V - 1.495 kVA 1x Plant 440 V - 546 kVA 1x Plant 24 V - 135 Ah 1x Plant 24 V - 135 Ah 1x Plant 24 V - 180 Ah |
|
Shaft generator |
1x 1.495 kW |
|
Generators |
2x Caterpillar C18 main diesel generatorsets each 546 kVA |
|
Emergency generator |
1x Caterpillar C18 main diesel generatorset 546 kVA |
|
Batteries |
1x Battery for automation 135 Ah |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster - 1.000 kW, forward |
|
Number of holds |
3 Hold 1: 28,91 x 16;06 x 10,76 m Hold 2: 29,61 x 18,70 x 10,76 m Hold 3: 29,61 x 18,70 x 10,76 m |
|
Number of hatches |
3 Hatch 1: 27,88 x 15,90 m Hatch 2: 28,86 x 18,70 m Hatch 3: 28,86 x 18,70 m |
|
Tank capacities |
Ballast: 4.547 m³ IFO: 792,85 m³ MDO: 179,59 m³ |
|
Anchor equipment |
3x Anchors weight each 5.610 kg Length: 577,50 m Diameter: 58 mm |
|
Cargo gear |
Gearless |
|
Crew size |
12 |
|
Manager |
MS "ELBTRADER" GmbH & Co. KG Germany |
|
ISM manager |
USC Barnkrug GmbH & Co. KG Am Elbdrich 76 21706 Drochtersen Germany |
|
Registered owner |
Contarga Ltd. c/o USC Barnkrug GmbH & Co KG Am Elbdeich 76 21706 Drochtersen Germany |
|
Latest data adjustment |
10 February 2023 |
