Westerschelde 21 July 2019 |
|
Name |
TOERMALIJN |
|
Previous names |
1971 Eiltank 19 1992 Rheintank 22 Manuela Emma 1999 - 2016 Liguria |
|
Type |
Inland tanker |
|
ENI-number |
02324023 |
|
Previous ENI-numbers |
4009580 5501800 6003017 |
|
Call sign |
PE3060 |
|
Flag |
The Netherlands |
|
Port of registry |
Zwolle |
|
GT |
1.615 t |
|
Tonnage |
2.617 t |
|
Length |
104,98 m overall |
|
Breadth |
11,40 m |
|
Draught |
3,72 m |
|
Air draft |
4,53 m |
|
Built |
1971 Transformation year: 1987 |
|
Builder |
Vahali Weserwerft Gendt The Netherlands |
|
Yard number |
440 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
13 |
|
Continuous decks |
1 |
|
Main engine |
1x ABC - 4 stroke 6 cylinder 256 x 310 mm diesel engine - 1.067 kW / 1.450 hp at 750 rpm Built: 1997 Builder: Anglo Belgian Corporation N.V. Wiedauwkaai 43, 9000 Gent - Belgium |
|
Propellers |
1x Screw propeller solid- aft at 375 rpm |
|
Generators |
1x Diesel generatorset 42 kVA - 34 kW 2x Diesel generatorsets each 63 kVA - 50 kW |
|
Bow thruster |
1x DAF 320 hp |
|
Number of cargo tanks |
12 |
|
Total capacity of tanks |
3.086 m³ |
|
Cargo handling |
2x Pumps 300 m³/h |
|
Previous names & owners |
1971 Eiltank 19 - Jaegers GmbH, Dbg Ruhrort - Germany 1992 Rheintank 22 - Stinnes GmbH, Dbg Ruhrort - Germany 1996 Manuela - Slokkers Handel & Scheepvaartonderneming BV, Hendrik ido Ambacht - The Netherlands 1997 Emma - Janssens, Schilde - Belgium 1999 Liguria - Sijbrands & Zn., Piershil - The Netherlands 2016 Toermalijn - Pieters Maritieme Dienstverlening, Lobith-Tolkamer - The Netherlands 2018 Toermalijn - Zwolle - The Netherlands |
|
Latest data adjustment |
12 October 2020 |
