| Antwerpen 20 April 2012 |
 |
 |
 |
||
| Antwerpen 20/04/12 | Antwerpen 20/04/12 | Antwerpen 20/04/12 |
|
Name |
MSC LIRICA |
|
Type |
Passenger ship - Cruise |
|
IMO-number |
9246102 |
|
Call sign |
HOPW |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
59.058 t |
|
DWT |
6.561 t |
|
NT |
33.747 t |
|
Length |
251,25 m overall 222,25 m between perpendiculars |
|
Breadth |
28,80 m extreme |
|
Draught |
6,80 m |
|
Freeboard |
Summer: 3.204 mm |
|
Depth |
34,85 m moulded |
|
Speed |
21,5 knots |
|
Built |
2003 |
|
Date of completion |
24.03.2003 |
|
Builder |
STX France SA (Chantiers de l'Atlantique) |
|
Yard number |
K32 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
19 |
|
Continuous decks |
14 |
|
Main engine |
Diesel/electric: 4x Wärtsilä type 12V/38A diesel engines - total output 30.600 kW at 600 rpm |
|
Electrical propulsion engine |
2x Alstom pods output each 10.000 kW total 27.174 hp at 170 rpm Builder: Alstom Marine, Nancy - France |
|
Electrical propulsion gen. |
4x 7.650 kW - 6.600 Volt |
|
Propelling system |
1x Pod solid - at 170 rpm |
|
Boilers |
2x CHO 85,10 m² - 8,0 bar |
|
Electrical installation |
Power voltage: 6.600 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Emergency generator |
1x Diesel generatorset 938 kVA - 750 kW - 1.202 hp |
|
Cargo holds |
23 |
|
Hold capacity |
1.722 m³ |
|
Passengers decks |
9 |
|
Pass. cap. lower beds |
1.560 |
|
All berths |
2.199 |
|
Manager |
MSC Mediterranean Shipping Co. 1206 Geneva, |
|
Operator |
MSC Cruises - Italy |
|
Owner |
Newco Lirica SA |
