Westerschelde 31 August 2016 |
 |
 |
||
| Westerschelde 17/04/17 | Vlissingen 31/10/18 | ||
|
Name |
BRUFJELL |
|
Previous names |
10/1995 - 12/1996 Saar Hamburg 12/1996 - 07/2014 Wolthusen |
|
Location |
Westerschelde 27 April 2017 |
|
Type |
General dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9115925 |
|
Classification |
DNV GL |
|
Call sign |
J8B5104 |
|
Flag |
Saint Vincent and the Grenadines |
|
Port of registry |
Kingstown |
|
Previous flags |
Germany Antigua & Barbuda Cyprus |
|
GT |
2.846 |
|
DWT |
Summer: 4.748,41 t with bulkheads Winter: 4.606,64 t |
|
DWCC |
Summer: 4.200 t Winter: 4.100 t |
|
NT |
1.584 |
|
Displacement |
Summer: 6.135,86 t Winter: 5.994,09 t |
|
Lightship |
1.358,2 t |
|
Number of 20ft containers |
In hold: 114 On hatches: 92 Total: 206 |
|
Length |
90,33 m overall 84,60 m between perpendiculars |
|
Breadth |
13,20 m extreme |
|
Draught |
Summer: 6,23 m Winter: 6,10 m |
|
Air draft |
24,00 m in ballast Max: 28,00 m |
|
Depth |
7,30 m moulded |
|
Speed |
11,5 knots |
|
Built |
1995 |
|
Keel laid |
13/12/1994 |
|
Launch date |
10/06/1995 |
|
Date of completion |
01/10/1995 |
|
Builder |
Bodewes Shipyards B.V. Hoogezand The Netherlands |
|
Yard number |
572 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Movable bulkheads |
2 |
|
Main engine |
1x Deutz-MWM SBV9M628 - 4 stroke 9 cylinder combustion engine 1.800 kW / 2.447 bhp at 900 rpm |
|
Propellers |
1x Controllable pitch propeller 4 blades |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 325 kW |
|
Generators |
2x Scania DS 9 main diesel generatorsets each 154 kW at 1.500 rpm |
|
Emergency generator |
1x Susu diesel/Valmet 420 DSG diesel generatorset 62 kW at 1.500 rpm |
|
Bow thruster |
1x 240 kW / 326 bhp |
|
Number of cargo holds |
1 65,00 x 10,58 x 8,50 m |
|
Hold ventilation |
6x Air/changes hour |
|
Cargo hold capacity |
Without bullheads Grain: 5.793,39 m³ / 204.587,99 ft³ Bale: 5.663,00 m³ / 199.989,00 ft³ |
|
Number of hatches |
1 65,00 x 10,58 m |
|
Hatch cover surface |
703,30 m² |
|
Hatch cover type |
MacGregor hydraulic folding |
|
Max permitted loads |
On deck: 1,6 t/m² Tanktop: 18,0 t/m² |
|
Tank capacities |
MDO: 230,85 m³ Fresh water: 34,32 m³ Lub oil: 14,69 m³ Ballast: 1.802,58 m³ Bilge: 4,90 m³ |
|
Lifting equipment |
Length:412,50 m Diameter: 36 mm |
|
Manager |
Kopervik Ship Management Poland Sp. z o.o. Wały Piastowskie 1 80-854 Gdańsk Poland |
|
Registered owner |
AAT Shipinvest AS Elvegaten 14 NO-4400 Flekkefjord Norway |
|
Sister ships |
03/1996 Lafjell - IMO 9115937 |
|
Renamed |
03/2021 Wagon B Antigua and Barbuda, St. John’s - Call sign: V2QV8
|
|
Latest data adjustment |
08 March 2026 |
