Westerschelde 08 June 2015 |
 |
|
| Westerschelde 21/07/15 | |
|
Name |
NAJLAND |
|
Previous names |
1989 - 03/2011 Najaden |
|
Type |
General cargo carrier (single deck) - Container |
|
IMO-number |
8806137 |
|
Call sign |
9HA2709 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
1989 - 2011 Finland, Nauvo - Call sign: OIZB 2011 - 2011 Finland, Helsingfors - Call sign: OIZB |
|
GT |
3.826 t |
|
DWT |
Summer: 4.402 t |
|
DWCC |
Summer: 4.200 t Winter: 4.100 t |
|
NT |
2.013 t |
|
Light displacement |
2.228 t |
|
Number of 20ft containers |
In hold: 140 On deck: 186 Total: 326 |
|
Container capacity 14t |
224 |
|
Length |
104,81 m overall 97,90 m between perpendiculars |
|
Breadth |
16,25 m extreme 16,00 m moulded |
|
Draught |
Summer: 5,78 m |
|
Air draft |
Masts not movable: Ballast: fore mast: 23,50 m Aft mast: 33,80 m |
|
Max height from keel |
Ballast: fore mast: 26,50 m Aft mast: 38,00 m |
|
Depth |
7,75 m moulded |
|
Speed |
Max: 15,4 knots Service: 14,0 knots |
|
Built |
1989 |
|
Keel laid |
22/11/1988 |
|
Launch date |
30/01/1989 |
|
Date of completion |
24/02/1989 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Germany |
|
Yard number |
1036 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull, double bottom (e.g. interrupted in way of machinery space) |
|
Watertight Bulkheads |
5 |
|
Movable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8R32DF - 4 stroke 8 cylinder 320 x 350 mm combustion engine 2.960 kW/ 4.024 bhp at 750 rpm |
|
Propellers |
1x KaMeWa controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler (Oil fired water heater) |
|
Shaft generator |
540 kW |
|
Generators |
2x Volco Penta TMD 102 A main diesel generatorsets each 158 kW |
|
Emergency generator |
1x Deutz KHD F 3L 912 diesel generatorset |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
1x Steel floor, boxshaped 65,78 x 12,82 x 8,25 m |
|
Cargo hold capacity |
Bale: 228.170 ft³ / 6.368 m³ Grain: 230.250 ft³ / 6.461 m³ |
|
Number of hatches |
1 65,00 x 12,80 m |
|
Max permitted loads |
Tanktop: 10,0 t/m² Hatch covers: 1,73 t/m² |
|
Tank capacities |
Ballast: 1.915,8 m³ |
|
Anchor equipment |
3x Anchors weight each 2.850 kg Length: 495,00 m Diameter: 42 mm |
|
Crew size |
12 |
|
Manager |
Klip Marine Shipmanagement OÜ Masti 12 11911 Tallinn Estonia |
|
Operator |
Klip Marine OÜ Tallinn Estonia |
|
Registered owner |
Najland Shipping Ltd. Valletta Malta |
|
Previous owners |
1989 - 03/2011 Rederi AB Engship - Finland |
|
Renamed |
10/2020 Najlan Saint Kitts and Nevis, Basseterre - Call sign: V4EZ4 Owner & manager: Najlan Shipping Ltd., Dubai - United Arab Emirates |
|
Latest data adjustment |
06 October 2024 |
