Westerschelde 02 April 2017 |
|
Name |
BUGOE |
|
Previous names |
2010 - 2011 Drentediep 2011 - 2017 Beringdiep |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9518969 |
|
Call sign |
A8ZL6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
2010 - 2011 Cyprus, Limassol - Call sign: 5BBA3 |
|
GT |
4.220 t |
|
DWT |
Summer: 5.728 |
|
NT |
2.456 t |
|
Number of 20ft containers |
In hold: 159 On deck: 85 Total: 244 |
|
Number of 40ft containers |
In hold: 60 On deck: 51 Total: 111 |
|
Length |
106,02 m overall 99,98 m between perpendiculars |
|
Breadth |
15,86 m extreme 15,20 m moulded |
|
Draught |
5,88 m fully laden |
|
Air draft |
27,50 m ballast |
|
Depth |
7,90 m moulded |
|
Speed |
11,0 knots |
|
Built |
2010 |
|
Keel laid |
10/09/2008 |
|
Launch date |
18/05/2010 |
|
Date of completion |
22/09/2010 |
|
Builder |
Rong Cheng Shipbuilding Industry Co., Ltd. Rongcheng China |
|
Yard number |
RC20 |
|
Hull material |
Steel |
|
Movable bulkheads |
2 |
|
Main engine |
1x Yanmar 6EY26 - 6 cylinder combustion engine 1.920 kW at 750 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 350 kW at 1.500 rpm - 400 Volt / 50 Hz |
|
Generators |
3x Deutz TBD234V8 main diesel engine each 249 kW at 1.500 rpm coupled with generator each 230 kW - 400 Volt / 50 Hz |
|
Emergency generator |
1x Deutz TBD234V8 diesel generatorset |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
2x Boxshaped Hold 1: 25,50 x 12,65 x 9,20 m (20,20 m length without narrowing) Hold 2: 45,75 x 12,65 x 9,20 m |
|
Hold capacity |
Hold 1: 102.385 ft³ Hold 2: 186.216 ft³ 288.601ft³ excl. bulkheads |
|
Hold ventilation |
6x Air-changes / hour in hold |
|
Number of hatches |
2 Hatch 1: 25,50 x 12,65 m Hatch 2: 45,75 x 12,65 m |
|
Hatch cover type |
Pontoon, 11 pcs (operated by gantry crane) |
|
Max permitted loads |
Tanktop: 15,00 t/m² Hatchcover: 2,20 t/m² Tweendeck: 2,40 t/m² |
|
Tank capacities |
HFO: 261,30 m³ MGO: 76,15 m³ Fresh water: 58,00 m³ Ballast water: 1.968,10 m³ |
|
Anchor equipment |
Length: 467,00 m Diameter: 40 mm |
|
Crew size |
11 |
|
Manager |
MTL Maritime Transport Duisburg Germany |
|
Registered owner |
MTL Maritime Transport Duisburg Germany |
|
Renamed |
2021 Amberland Portugal, Madeira - Call sign: CQEF9 Owner: Tomden Ship 148 GmbH & Co., KG - Germany Manager: Tom Worden GmbH & Co. KG - Germany |
|
Latest data adjustment |
17 March 2018 |
