Westerschelde 27 December 2017 |
|
Name |
EEMS SUN |
|
Type |
General cargo ship - Heavycargo |
|
IMO-number |
9431587 |
|
Call sign |
PHMO |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
1.862 t |
|
DWT |
Summer: 2.600 t |
|
DWCC |
Summer & Winter: 2.530 t |
|
NT |
920 t |
|
Length |
87,27 m overall 83,20 m between perpendiculars |
|
Breadth |
11,45 m |
|
Draught |
4,26 m |
|
Air draft |
8,70 m |
|
Freeboard |
1.599 mm |
|
Depth |
5,85 m |
|
Speed |
10,5 knots |
|
Built |
2009 |
|
Date of completion |
15/02/2009 |
|
Builder |
Hong Ha shipbuilding |
|
Yard number |
HH-06 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6DZC - 4 stroke single acting 6 cylinder 256 x 310 mm combustion engine 1.104 kW / 1.500 hp at 800 rpm Built: 11/07/2008 Builder:Anglo Belgian Corporation NV Wiedauwkaai 43 9000 Gent Belgium |
|
Propellers |
1 Screw propeller controllable pitch - aft at 320 rpm 4 Blades |
|
Shaft generator |
1x 290 kVA - 232 kW |
|
Generators |
1x Sisu 634-DSBG 108 x 134 mm diesel engine 138 kW coupled with generator 151 kVA at 1.500 rpm |
|
Emergency generator |
1x Sisu 420-DSRG 108 x 120 mm diesel engine 70 kW coupled with generator 77 kVA at 1.500 rpm |
|
Bow thruster |
1x Veth VT-200 thruster - 200 kW |
|
Number of holds |
1 56,19 x 9,00 x 6,70 m |
|
Cargo hold capacity |
Grain/Bale: 119.500 ft³ / 3.389m³ |
|
Number of hatches |
1 56,19 x 9,00 m |
|
Hatch type |
Pontoon |
|
Max permitted loads |
Tanktop: 12,0 t/m² Deck: 1,6 t/m² |
|
Tank capacities |
Fuel oil: 121,79 m³ Water ballast: 1.400 m³ |
|
Manager |
Amasus Shipping B.V. |
|
Owner |
Scheepvaartonderneming Germa C.V. |
|
Registered owner |
Sun B.V. |
|
Latest data adjustment |
15 March 2018 |
