Medi Manila 01

Spijkenisse 20 November 2015



Name

MEDI MANILA

Type

Panamax bulk carrier - Strengthened for heavy cargo loading

IMO-number

9660607

Call sign

3FEI5

Flag

Republic of Panama

Port of registry

Panama City

GT

32.370 t registered

DWT

Summer: 57.370 t

NT

19.435 t registered

Length

189,99 m overall

Breadth

32,26 m moulded

Draught

Summer: 12,83 m

Moulded L x B x D

185,60 x 32,26 x 18,00 m

Registered L x B x D

185,78 x 32,26 x 18,00 m

Freeboard

Summer: 5.225 mm

Depth

18,00 m moulded

Speed

Max.: 16,3 knots

Service: 14,0 knots

Built

2014

Keel laid

16.01.2014

Launch date

08.05.2014

Date of completion

10.07.2014

Builder

Tsuneishi Group (Zhoushan) Shipbuilding Inc.
Fukuyama
Japan

Yard number

SS-135

Hull material

Steel

Hull type

Single hull

Main engine

1x 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine 8.200 kW at 108,0 rpm

Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works

Propeller shaft

1x Oil lubrication shaft without monitoring device

Diameter: 510 mm

Propellers

1

Boilers

1x Auxiliary vertical boiler - 7,0 bar

Evaporation: 2,72 t/h

Manufacturer: Osaka Boiler Mfg., Co., Ltd.

Generators

4x Generators - 2.125 kVA

Number of holds

5

Hold capacity

Bale: 69.348 m³

Grain: 72.607 m³

Number of hatches

5

Tank capacities

Fuel oil: 2.350 m³

Fresh water: 312 m²

Water ballast: 16.201 m³

Cargo gear

4x Cranes - SWL 30,0 t each

Grabs: 4x 12 t each

Manager

Daiichi Chuo Marine Co., Ltd.
Yokyo
Japan

Operator

d'Amico

Registered owner

DD Shipping S.A.

Latest data adjustment

08 June 2016
