Malaga - Spain 25 February 2016 |
 |
 |
|
| Malaga, Spain 25/02/16 | Westerschelde 06/06/19 |
|
Name |
ARKLOW WIND |
|
Type |
General cargo ship - strengthened for heavy cargo |
|
IMO-number |
9287314 |
|
Call sign |
EIKZ |
|
Flag |
Ireland |
|
Port of registry |
Arklow |
|
GT |
8.938 t |
|
DWT |
Summer: 13.988 t |
|
NT |
4.815 t |
|
Displacement |
17.873 t |
|
Length |
136,43 m overall 126,88 m between perpendiculars |
|
Breadth |
21,60 m extreme |
|
Draught |
Summer: 8,35 m |
|
Air draft |
Min.: 30,00 m |
|
Freeboard |
2.962 mm |
|
Depth |
11,30 m moulded |
|
Speed |
13,3 knots |
|
Built |
2004 |
|
Delivery date |
15/01/2004 |
|
Builder |
Kyokuyo Shipyard Corporation Shimonoseki Japan |
|
Yard number |
448 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L38B - 4 stroke single acting 6 cylinder 380 x 475 mm combustion engine 4.320 kW / 5.910 hp at 600 rpm Built: 2003 Builder: Wärtsilä Italia S.p.A., Trieste - Italy |
|
Propellers |
1x Screw propeller controllable pitch - aft at 139 rpm |
|
Boilers |
1x CHR Miura 47,90 m² |
|
Electric installations |
Power voltage: 390 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
1x 1.194 kVA - 955 kW |
|
Generators |
2x Yanmar diesel generatorsets each 600 kVA - 480 kW - 747 hp |
|
Emergency generator |
1x Deutz diesel engine 114 kW coupled with Taiyo generator 100 kW |
|
Bow thruster |
1x 526 kW |
|
Number of holds |
4 |
|
Total capacity of holds |
Grain / Bale Hold 1: 3.234 m³ - 114.215 ft³ / 3.131 m³ - 110.581 ft³ Hold 2: 5.321 m³ - 187.902 ft³ / 5.177 m³ / 182.822 ft³ Hold 3: 5.439 m³ - 192.073 ft³ / 5.293 m³ / 186.926 ft³ Hold 4: 3.317 m³ - 117.143 ft³ / 3.240 m³ - 114.409 ft³ Total: 17.311 m³ - 611.333 ft³ / 16.841 m³ / 594.738 ft³ |
|
Hold ventilation |
Mechanical ventilation – 20 changes per hour in empty holds |
|
Cargo hatchways |
4 1x 14,00 x 12,60 m 2x 21,00 x 17,60 m 1x 12,60 x 17,60 m |
|
Hatch type |
Weather tight folding type |
|
Max. permitted loads |
Tanktop: 20 t/m² Hatches: 1,8 t/m² |
|
Tank capacities |
Fuel oil: 800 m³ Ballast: 4.100 t Diesel oil: 160 m³ Fresh water: 200 m³ |
|
Manager |
Arklow Shipping Ltd. Arklow Ireland |
|
Operator |
Arklow Shipping |
|
Owner |
Coastal Shipping Plc. Arklow Irish Republic |
|
Renamed |
06/2017 Longwave The Netherlands, Schoonhoven - Call sign: PDGK Manager: Longship B.V., Groningen - The Netherlands Owner: BBS Bulk V AS, Bergen - Norway |
|
Latest data adjustment |
09 May 2021 |
