Arklow Willow - IMO 9818955

Name

ARKLOW WILLOW

Type

General cargo vessel - Heavycargo - Occasional dry bulk cargo

IMO-number

9818955

Call sign

EIVV3

Flag

Ireland

Port of registry

Arklow

GT

9.999 t

DWT

Summer: 16.791,4 t

Winter: 16.315,7 t

NT

5.155 t

Length

149,50 m overall

145,50 m between perpendiculars

Breadth

19,25 m moulded

Draught

Summer: 8,60 m

Winter: 8,43 m

Ballast: 5,10 m

Air draft

Min: 28,80 m

Freeboard

3.426 mm

Speed

Max: 16,4 knots

Service: 10,7 knots

Built

2019

Keel laid

14/12/2015

Launch date

06/09/2019

Date of completion

25/10/2019

Builder

Scheepswerf Ferus Smit

Leer

Germany

Yard number

449

Hull material

Steel

Movable bulkheads

2x Moveable bulkheads with 9 positions

Continuous decks

1

Main engine

1x MaK - 4 stroke 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.217 hp at 600 rpm

Build: 13/11/2018

Builder: Caterpillar Motoren GmbH & Co. Kg., Kiel - Germany

Propellers

1x Screw Propeller Controllable pitch - aft at 110,0 rpm

Generators

2x Main diesel generatorsets each 500 kVA - 400 kW - 595 hp

Emergency generator

1x Diesel generatorset 125 kVA - 100 kW - 158 hp

Number of holds

2

Cargo hold capacity

Hold 1:

7.540,0 m³ / 266.275 ft³ bulkheads

7.341,6 m³ / 259.254 ft³ bulkheads stowed

Hold 2:

12.176,7 m³ / 430.020 ft³ b/heads

11.977,0 m³ / 422.944 ft³ b/heads stowed

Hold ventilation

Mechanical ventilation: 6 changes/h

Dehumidifiers for holds

Number of hatches

2

Hatch 1: 42,00 x 16,05 x 11,80 m

Hatch 2: 64,00 x 16,05 x 11,80 m

Hatch type

Coops & Nieborg pontoon

Max permitted loads

Tanktop: 20 t/m²

Tank capacities

Fuel: 586,72 m³

ISM & commercial manager

Arklow Shipping

North Beach

Arklow

Co. Wicklow

Ireland

Registered owner

Glenart Shipping Limited

Care of Arklow Shipping Unlimited Co (Arklow Shipping ULC),

North Quay, Arklow, Co Wicklow

Ireland

Latest data adjustment

08 January 2023
