Westerschelde 23 November 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 23/11/15 | Westerschelde 05/11/16 | Antwerpen 06/07/17 | Antwerpen 16/08/17 | Antwerpen 16/08/17 | Westerschelde 21/06/18 | |||||
 |
||||||||||
| Westerschelde 17/04/19 |
|
Name |
ANMIRO |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Grain and timber fitted - Equipped for dangerous goods Sea-Rhein trader |
|
IMO-number |
9434577 |
|
Call sign |
V2DR9 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
2.461 t |
|
DWT |
Summer: 3.670 |
|
NT |
1.396 t |
|
Number of 20ft containers |
In hold: 108 On deck: 36 Total: 144 |
|
Number of 40ft containers |
In hold 16 + 4 TEU On deck: 48 + 12 TEU Total: 64 + 16 TEU |
|
Length |
87,97 m overall 81,32 m between perpendiculars |
|
Breadth |
12,90 m extreme |
|
Draught |
5,49 m |
|
Keel to mast end |
24,00 m |
|
Depth |
7,10 m |
|
Speed |
11,5 knots |
|
Built |
2009 |
|
Keel laid |
09/06/1998 |
|
Launch date |
17/10/2008 |
|
Date of completion |
19/01/2009 |
|
Builder |
Slovenske Lodenice A.S. Rolnickej Skoly 1519 945 01 Komarno Slovak Republic |
|
Yard number |
2968 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Movable bulkhead |
2x Movable, can be placed in 10 positions |
|
Main engine |
1x MaK 8M20 - 4 stroke 8 cylinder 200 x 300 mm combustion engine 1.520 kW at 1.000 rpm Year of manufacture: 2007 Manufacturer: Caterpillar Motoren GmbH & Co. KG, Falckensteiner Str. 2, 24159 Kiel - Federal Republic of Germany |
|
Propellers |
1x Fixed pitch propeller - aft at 226 rpm |
|
Generators |
3x SISU 49.492 CTAG-4V diesel generatorsets each 110 kW |
|
Emergency generator |
1x SISU-320-DSG 320 diesel generatorset 53 kW at 1.500 rpm |
|
Bow thruster |
1x Jastram type Bu 40 F - 185 kW with fixed pitch propeller, forward |
|
Number of holds |
1 56,55 x 10,20 x 8,15 m |
|
Hold capacity |
Grain: 4.600 m³ Bale: 4.588 m³ |
|
Hold ventilation |
6x Air-changes per hour |
|
Number of hatches |
1 56,55 x 10,20 m |
|
Hatch cover type |
Hydraulic folding type |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Deck: 1,0 t/m² |
|
Tank capacities |
MDO: 165,00 m³ Ballast: 1.600,00 m³ Freshwater: 58,00 m³ Lube oil: 8,00 m³ |
|
Anchor equipment |
3x Anchors weight each 1.740 kg Length: 440,00 m Diameter: 32 mm |
|
Cargo gear |
Gearless |
|
Accommodation |
9 persons |
|
Commercial manager |
Briese Schiffahrts Gmbh & Co. Hafenstraße 12 26789 Leer Germany |
|
ISM manager |
Briese Dry Cargo GmbH & Co. KG Hafenstraße 12 26789 Leer Germany |
|
Registered owner |
Briese Schiffahrts GmbH & Co. KG MS "DEDDEBORG" Care of Briese Schiffahrts GmbH & Co KG Hafenstrasse 12 26789 Leer Germany |
|
Latest data adjustment |
13 March 2022 |
