Trinityborg 01

Westerschelde 30 May 2015



Name

TRINITYBORG

Type

Multi-purpose dry cargo carrier / Container carrier

IMO-number

9546485

Call sign

PCWU

Flag

The Netherlands

Port of registry

Delfzijl

GT

14.695 t

DWT

Summer: 21.050 t

NT

6.695 t

Number of 20ft containers

1.221

Reefer plugs

72

Length

172,28 m overall

162,65 m between perpendiculars

Breadth

21,49 m moulded

Draught

Max.: 9,38 m

Air draft

35,85 m

Depth

13,31 m moulded

Speed

17,0 knots

Built

2013

Keel laid

10.05.2013

Launch date

06.08.2013

Date of completion

14.11.2013

Builder

Hudong Zhonghua Shipbuilding Group
Shanghai
China

Yard number

1598A

Hull material

Steel

Continuous decks

1

Main engine

1x Wärtsilä 6L46F - 4 stroke single acting 6 cylinder 460 x 580 mm diesel engine - 7.500 kW at 600 rpm

Propellers

1x Wärtsilä / Lips - 4 blades - Diameter: 4.800 mm

Number of holds

2

Hold 1: 55,42 x 17,75 x 13,35 m

Hold 2: 58,68 x 17,75 x 13,35 m

Cargo hold capacity

Hold 1: 12.316,41 m³

Hold 2: 13.973,34 m³

Hold ventilation

Air changes per hour basis empty holds:

12 x In hold 1

8 x In hold 2

Both holds fitted with dehumidifier units

Number of hatches

2

Hatch 1: 55,42 x 17,75 m

Hatch 2: 58,68 x 17,75 m

Hatch type

Cargotech MacGregor hydraulic steel pontoons hatches

Floor space

Tank Top: 1.892,99 m²

Tween Deck: 2.025,27 m²

Weather Deck: 2.147,75 m²

Max. permissible load

Weather Deck Hatch Covers: 1,75 t/m²

Tween Deck Hatch Covers: 4,00 t/m²

Tank Top: 20,00 t/m²

Cargo gear

4x Liebherr deck cranes fixed on portside -SWL 60,0 t each

Manager

Wagenborg Shipping
Marktstraat 10
9934 CK Delfzijl

The Netherlands

Operator

AAL - Schoeller Holdings group

Owner

C.V. m.s. Trinityborg
Delfzijl
The Netherlands

Latest data adjustment

12 August 2015
