Federal Skeena - IMO 9595890

Antwerpen 27 April 2015

Name

FEDERAL SKEENA

Type

Bulk carrier

IMO-number

9595890

Call sign

V7WS5

Flag

Marshall Islands

Port of registry

Majuro

GT

24.196 t

DWT

Summer: 37.168 t

Winter: 36.055 t

NT

12.205 t

Panama: 20.144 t

Length

189,99 m overall

Breadth

28,31 m

Draught

10,51 m

Depth

15,20 m

Speed

14,0 knots

Built

2012

Builder

Zhejiang Ouhua Shipbuilding
Zhoushan
China

Hull material

Steel

Number of holds

5

Hold 1: 25,60 x 9,1 / 20,20 m

Hold 2: 28,80 x 20,02 / 20,02 m

Hold 3: 26,40 x 20,02 / 20,02 m

Hold 4: 28,80 x 20,02 /20,02 m

Hold 5: 28,80 x 20,02 / 7,20 m

Hold capacity

Grain / bale:

Hold 1: 7.604 m³ / 7.400 m³

Hold 2: 10.757 m² / 10.551 m³

Hold 3: 9.884 m³ / 9.683 m³

Hold 4: 10.757 m² / 10.551 m³

Hold 5: 9/901 m³ / 9.746 m³

Total: 48.903 m³ / 47.931 m³

Number of hatches

5

Hatch 1: 16,00 x 15,00 m

Hatch 2: 22,40 x 18,00 m

Hatch 3: 19,20 x 18,00 m

Hatch 4: 22,40 x 18,00 m

Hatch 5: 22,40 x 18,00 m

Hatch covert type

Folding Hydraulic

Max permitted loads

Tanktop: 25,0 t/m²

Tank capacities

Fuel oil: 1.354 m³

Gas oil: 280 m³

Cargo gear

4x Electro hydraulic cranes - SWL 30,0 t each

Manager

Anglo Eastern Shipmanagement
Hong Kong
China

Owner

Fednav Group
1000 de La Gauchetière Street West, Suite 3500
Montreal

Quebec

Canada

Latest data adjustment

27 January 2015
