Westerschelde 29 June 2014 |
 |
 |
||
| Westerschelde 29/06/14 | Westerschelde 29/06/14 |
|
Name |
TREASURE |
|
Previous names |
1990 - 01.1993 Jahre Traveller 01.1993 - 09.2000 Nord Jahre Traveller 09.2000 - 03.2003 Crude Traveller 03.2003 - 08.2004 Genmar Traveller 08.2004 - 04.2008 Front Traveller |
|
Type |
Semi submersible heavy lift cargo ship |
|
IMO-number |
8617940 |
|
Call sign |
PJNS |
|
Flag |
|
|
Port of registry |
Willemstad |
|
Previous flags |
1990 - 2000 Norway 2000 - 2001 Liberia 2001 - 2003 Greece 2003 - 2008 Marshall Islands |
|
GT |
42.515 t |
|
DWT |
Summer: 53.868 t |
|
NT |
12.755 t |
|
Length |
216,86 m overall 207,82 m between perpendiculars |
|
Breadth |
44,44 m moulded |
|
Draft |
Submerged at FPP/APP: 23,00 m Max.: 10,75 m |
|
Depth |
14,00 m |
|
Speed |
15,00 knots |
|
Built |
1990 |
|
Keel laid |
29.07.1989 |
|
Launch date |
03.02.1990 |
|
Date of completion |
18.07.1990 |
|
Builder |
Brodogradiliste Split Shipyard 2008 by COSCO (Zhoushan) Shipyard Co. Ltd., Zhoushan - China converted from a tanker to heavy cargo ship built new midship 30.06.2008 delivery by the yard to Dockwise Transport Ltd. |
|
Yard number |
362 |
|
Hull material |
Steel |
|
Hull type |
Single bottom Single side |
|
Watertight bulkheads |
Transverse: 11 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 6S70MC-C- 2 stroke single acting 700 x 2.674 mm diesel engine - 11.952 kW Manufacturer: Tvornica Dizel Motora, Pula - Croatia |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated Builder: Sunrod 1x Auxiliary boiler, oil/gas fired Builder: Saacke Qingdao Marine Boiler Co. Ltd. |
|
Generators |
3x MAN 6L28/32H diesel generatorsets Builder: MAN Diesel & Turbo SE |
|
Emergency generator |
1x MWM TBD 234V06 diesel generatorset |
|
Bow thruster |
1x 1.500 kW, forward |
|
Total installed power |
15.552 kW |
|
Deck space |
130,00 x 44,50 m |
|
Balasting |
4x Main ballast pumps (steam driven) 2.500 m³/h at 30 m head 1x Ballast pump (electric driven) 4.000 m³/hr at 30 m head 1x Stripping pump 500 m³/h at 140 m head 1x One stripping ejector 300 m³/h at 20 m head 2w Drain tank pumps 300 m³/h at 50 m head 1x Fire pump 110 m³/h at 80 m head 1x Fire gen. service pump 110 m³/h at 80 m head 1x Emergency fire pump 72 m³/h at 80 m head |
|
Anchor equipment |
Length: 715 m Diameter: 92 mm |
|
Manager |
Anglo Eastern Shipmanagement Ltd. |
|
Previous managers |
1990 - 2003 Metrostar Management Corp. 2003 - 2004 General Maritime Management (Hellas) Ltd. 2004 - 2008 Wallem Shipmanagement Ltd. 2008 - 2011 Anglo-Eastern (UK) Ltd. |
|
Operator |
Dockwise Lage Mosten 21 The Netherlands |
|
Registered owner |
Treasure BV |
|
Previous owners |
1990 - 2000 Park Pacific Company 2000 - 2003 Potamis maritime Corporation 2003 - 2004 GMR Traveller LLC. 2004 - 2008 Front Traveller Inc. 2008 - 2011 Treasure BV 2011 - 2012 Traveller BV |
|
Latest data adjustment |
13 January 2015 |
