Westerschelde 02 Augst 2014 |
 |
| Westerschelde 30/06/14 |
|
Name |
HANJIN ODESSA |
|
Type |
Bulk carrier |
|
IMO-number |
9539729 |
|
Call sign |
3FXS |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
63.993 t |
|
DWT |
Summer: 114.536 t |
|
NT |
38.040 t |
|
Length |
255,24 m overall |
|
Breadth |
43,00 m |
|
Draught |
14,52 m |
|
Reg. Dimensions L x B x D |
248,74 x 42,99 x 20,20 m |
|
Rule Dimensions L x B x D |
248,75 X 43,00 X 20,20 m |
|
Freeboard |
Summer: 5.734 mm |
|
Depth |
20,20 m registered |
|
Speed |
14,5 knots |
|
Built |
2012 |
|
Keel laid |
15.12.2008 |
|
Launch date |
21.12.2011 |
|
Date of completion |
13.04.2012 |
|
Builder |
New Times Shipbuilding Co., Ltd. |
|
Yard number |
H-0111519 |
|
Hull material |
Steel |
|
Hull type |
Double buttom |
|
Watertight bulkheads |
Transverse: 9 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Hyundai - 2 stroke single acting 6 cylinder 600 x 2.400 mm diesel engine - output 13.560 kW / 18.436 hp at 105,0 rpm Built: 04.2011 Builder: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 105,0 rpm |
|
Generators |
4x Diesel generatorsets each 800 kVA 450 Volt |
|
Cargo capacity |
Grain: 134.030 m³ |
|
Number of hatchway |
7 Hatch 1: 16,72 x 18,10 m Hatch 2: 18,48 x 20,40 m Hatch 3: 18,48 x 20,40 m Hatch 4: 18,48 x 20,40 m Hatch 5: 18,48 x 20,40 m Hatch 6: 18,48 x 20,40 m Hatch 7: 18,48 x 18,10 m |
|
Tank capacities |
Fuel oil: 3.563 m³ Fresh water: 649 m² Water ballast: 36.683 m³ |
|
Manager |
Hanjin Shipping Co., Ltd. |
|
Technical manager |
Hanjin Shipmanagement Co., Ltd. |
|
Registered owner |
Marlow Maritime Inc. |
|
Latest data adjustment |
29 September 2014 |
