Malaga - Spain 30 January 2014 |
|
Name |
PANDA |
|
Type |
Multi-purpose dry cargo carrier - Heavycargo |
|
IMO-number |
9201968 |
|
Call sign |
PBCS |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
2.088 t |
|
DWT |
Summer: 2.953 t |
|
NT |
1.168 t |
|
Number of 20ft containers |
108 |
|
Length |
88,95 m overall 84,95 m between perpendiculars |
|
Breadth |
12,40 m |
|
Draught |
4,35 m |
|
Air draft |
9,30 m |
|
Freeboard |
1.020 mm |
|
Depth |
5,65 m |
|
Speed |
Service: 10,5 knots |
|
Built |
2001 |
|
Launch date |
03/04/2001 |
|
Date of completion |
20/07/2001 |
|
Builder casco |
CSPL - Ceskoslovenska Plavba Labska A.S. Decin Czech Republic |
|
Builder completion |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
472 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8L20 - 4 stroke single acting 8 cylinder 200 x 280 mm combustion engine 1.440 kW / 1.958 hp at 1.000 rpm Built: 2001 Builder: Wärtsilä NSD Corporation, Vaasa - Finland |
|
Propellers |
1x Fixed pitch propeller - aft at 241 rpm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 220 V |
|
Generators |
2x Diesel generatorsets each 112 kVA - 90 kW - 150 hp |
|
Emergency generator |
1x Diesel generatorset 77 kVA - 62 kW - 95 hp |
|
Bow thruster |
1x Tunnel thruster 280 kW / 381 bhp, forward |
|
Number of holds |
1 62,40 x 10,24 x 6,70 m |
|
Cargo capacity |
Grain: 3.877 m³ / 151.000 ft³ |
|
Cargo hatchways |
1 62,40 x 10,24 m |
|
Crew size |
9 |
|
Manager |
Wagenborg Shipping Marktstraat 10 9934 KK Delfzijl The Netherlands |
|
Registered owner |
Eems Beheer XI B.V. Delfzijl The Netherlands |
|
Previous owner |
07/2001 - 09/2020 C.V. Scheepvaartonderneming Panda (H.J. Held) Delfzijl The Netherlands |
|
Renamed |
12/2001 Amadeus Diamond The Netherlands, Druten - Call sign: PBCS Manager: De Bock Maritiem B.V., Alkmaar - The Netherlands Owner: Amadeus Diamond B.V., Druten - The Netherlands |
|
Latest data adjustment |
12 February 2022 |
