Westerschelde 21 April 2020 |
 |
 |
|
| Antwerpen 31/12/13 | Antwerpen 16/06/17 |
|
Name |
IJSSELDIJK |
|
Previous names |
2009 Launch as: JRS Aquarius |
|
Type |
Multi-purpose dry cargo ship - Strengthened for heavy cargo Steelflorored, gearless, singledecker Fully ITF fitted, Grain fitted |
|
IMO-number |
9514913 |
|
Call sign |
PBUY |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
2.984 t |
|
DWT |
Summer: 4.891 t |
|
NT |
1.598 t |
|
Number of 20ft containers |
148 |
|
Length |
89,95 m overall 84,94 m registered |
|
Breadth |
14,40 m registered |
|
Draught |
6,22 m |
|
Depth |
7,85 m |
|
Speed |
11,5 knots |
|
Built |
2009 |
|
Keel laid |
29/04/2008 |
|
Launch date |
28/01/2009 |
|
Date of completion |
03/11/2009 |
|
Builder |
Chowgule & Company Pvt. Ltd. Shipbuilding Division Loutulim Near Borim Bridge Loutulim Road Loutulim, 403718 Goa Republic of India |
|
Yard number |
C0188 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
2 |
|
Movable bulkhead |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.980 kW at 750 mm Year of manufacture: 2007 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft ta 158 rpm |
|
Boilers |
1x Water heater, oil fired - 4,0 bar Manufacturer: Viessmann Werke GmbH & Co. Viessmann Str. 1 35107 Allendorf (Eder) Federal Republic of Germany |
|
Electric installations |
1x Plant 400 V - 210 kVA 1x Plant 400 V - 310 kVA 1x Plant 400 V - 210 kVA |
|
Shaft generator |
1x 310 kVA |
|
Generators |
1x Diesel generatorset 210 kVA |
|
Emergency - harbour gen. |
1x Diesel generatorset 210 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar 1x Receiver 10 litres - 7,0 bar |
|
Number of holds |
1 62,25 x 11,70 x 8,20 m |
|
Hold capacity |
Grain / Bales: 202.291 ft³ |
|
Number of hatches |
1 62,25 x 11,70 m |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440,00 m Diameter: 36 mm |
|
Manager |
Navigia Shipmanagement B.V. Bornholmstraat 82 9723 AZ Groningen The Netherlands |
|
Operator |
Apollo shipping GmbH & Co., KG Germany |
|
Registered owner |
Beheermaatschappij M.S. " IJSSELDIJK" B.V. Johan van Zwedenlaan 1 9744 DX Groningen The Netherlands |
|
Latest data adjustment |
25 March 2021 |
