Antwerpen 18 January 2014 |
|
Name |
HIZIR |
|
Previous names |
2007 - 07.2010 Lehmann trader 2010 - 12.2012 Pacific Sun 2012 - 03.2013 Pati 2013 - 07.2013 Ati |
|
Type |
General cargo ship |
|
IMO-number |
9396529 |
|
Call sign |
9HA3348 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.287 t |
|
DWT |
Summer: 7.750 t |
|
DWCC |
Summer: 7.400 t Winter: 7.300t |
|
NT |
3.393 t |
|
Number of 20ft containers |
In hold: 176 On deck: 288 On stern: 18 Total: 482 |
|
Container capacity 14t |
320 |
|
Length |
120,80 m overall 113,50 m between perpendiculars |
|
Breadth |
17,60 m |
|
Draught |
Max.: 6,25 m |
|
Air draft |
23,9 m in ballast 18,5 m without mast |
|
Freeboard |
1.870 mm |
|
Depth |
8,30 m moulded |
|
Speed |
13,0 knots |
|
Built |
2007 |
|
Date of completion |
06.02.2007 |
|
Builder |
Hongsheng Shipbuilding |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x Diesel/Gas turbine - 4 stroke 6 cylinder 400 x 420 mm combustion engine output 2.868 KW / 3.845,99 hp at 520 rpm |
|
Propellers |
1x Screw propeller solid |
|
Boilers |
1x CHM 24,00 m² - 7,0 bar |
|
Generators |
1x Diesel generatorset 144 kVA - 115 kW - 156 hp |
|
Number of holds |
Hold 1: 29,70 x 15,60 x 7,28 m (9,00 m under hatch) = 3.543,275 m³ Hold 2: 29,04 x 15,60 x 7,28 m (9,00 m under hatch) = 3.729,604 m³ Hold 3: 27,72 x 15,60 x 7,28 m (9,00 m under hatch) = 3.400,072 m³ |
|
Total hold capacity |
Bales & grain: 10.676,9 m³ / 377.054,7 ft³ |
|
Number of hatches |
3 Hatches 1,2,3: 25,08 x 12,50 m |
|
Hatch covers |
Electric, hydraulic folding type |
|
Max permitted loads |
Hatch cover strength: 6,0 t/m² Tank top strength: 12,0 t/m² |
|
Fuel capacity |
408,4 m³ |
|
Manager |
Unimarin Denizcilik San. ve Tic. Ltd. Şti. Emek Mh. Nato Yolu No:282 Kat :2 Sancaktepe |
|
Registered owner |
Eurasia South Shipping Ltd. |
|
Latest data adjustment |
01 March 2014 |
