Westerschelde 10 October 2019 |
 |
 |
|
| Antwerpen 22/05/13 | Malaga; Spain 16/02/15 | |
|
Name |
ARKLOW MILL |
|
Type |
General cargo ship - Heavy cargo |
|
IMO-number |
9440265 |
|
Call sign |
EIJD9 |
|
Flag |
Ireland |
|
Port of registry |
Arklow |
|
GT |
9.758 |
|
DWT |
14.990 t |
|
NT |
5.240 |
|
Displacement |
19.700 t |
|
Length |
136,47 m overall 128,50 m between perpendiculars |
|
Breadth |
21,00 m moulded |
|
Draught |
Summer: 8,88 m |
|
Air draft |
29,10 m minimum |
|
Freeboard |
2.938 mm |
|
Depth |
11,40 m moulded |
|
Speed |
14,5 knots |
|
Built |
2010 |
|
Date of completion |
02/05/2010 |
|
Builder |
Mokpo Shipbuilding Industry Co., Ltd. Mokpo South Korea |
|
Yard number |
07-191 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M43C - 4 stroke 6 cylinder 430 x 610 mm combustion engine 5.400 kW / 7.337 hp at 500 rpm Built: 14/07/2009 Builder: Caterpillar Motoren Rostock GmbH, Rostock - Germany |
|
Propellers |
1x Rolls Royce screw propeller controllable pitch - aft at 500 rpm |
|
Boilers |
1x CHO 628.07 A - 29,00 m² - 10,0 bar 1x CHR 628.07 B - 115,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.190 kVA - 952 kW |
|
Generators |
2x Yanmar main diesel engines 438 kW connected with Taiyo Electric generator 350 kW each |
|
Emergency generator |
1x STX diesel engine 100 kW connected with Taiyo Electric generator 100 kW |
|
Bow thruster |
1x 750 kW |
|
Number of holds |
4 |
|
Total capacity of holds |
Hold 1: 3.132 m³ / 110.600 ft³ Hold 2: 5.762 m³ / 203.480 ft³ Hold 3: 5.628 m³ / 198.742 ft³ Hold 4: 3.587 m³ / 126.668 ft³ Total: 18.110 m³ / 639.490 ft³ |
|
Number of hatches |
4 |
|
Hatch type |
Weather tight folding type |
|
Max permitted loads |
On hatches: 1,8 t/m² Tank top: 20 t/m² |
|
Tank capacities |
Water ballast: 5.480 t Fuel oil: 626 m³ Diesel oil: 143 m³ Fresh water: 136 m³ |
|
Hold ventilation |
6x Mechanical changes per hour in empty holds |
|
ISM & commercial manager |
Arklow Shipping ULC Hoofdweg 18 3067 GH Rotterdam The Netherlands |
|
Registered owner |
Coastal Shipping Plc Care of Arklow Shipping Unlimited Co (Arklow Shipping ULC) North Quay, Arklow, Co Wicklow Ireland |
|
Latest data adjustment |
26 December 2025 |
