Panta Rhei - IMO 9489522

Name

PANTA RHEI

Type

General cargo ship - heavy cargo - Super Saimamax

IMO-number

9489522

Call sign

PBRB

Flag

The Netherlands

Port of registry

Vlissingen

GT

2.409 t

DWT

3.755 t

DWCC

Summer: 3.500 t

NT

1.034 t

Number of 20ft containers

132

Length

82,50 m overall

80,84 m between perpendiculars

Breadth

12,50 m

Draught

Summer: 5,46 m

Air Draft

13,50 m

Freeboard

2.558 mm

Depth

8,00 m moulded

Speed

11,5 knots

Built

2009

Lunch date

06/11/2008

Date of completion

17/04/2009

Builder casco

Shipyard Leda d.o.o.

Korcula

Croatia

Builder completion

Peters Shipyard BV

Kampen

The Netherlands

Yard number: 1015

Hull material

Steel

Continuous decks

1

Watertight compartments

4

Main engine

1x Caterpillar 3512 - 4 stroke single acting 9 cylinder combustion engine 1.249 kW / 1.697 bhp at 1.600 rpm

Built: 11/2006

Builder: Caterpillar Tractor Company Inc., Peoria (Illinois) - U.S.A.

Propellers

1x Controllable pitch propeller - aft at 239 rpm

Shaft generator

1x 390 kVA - 312 kW

Diesel generators

1x Diesel generatorset 159 kVA - 127 kW - 247 hp

Bow thruster

220 kW

Number of holds

1

54,60 x 10,30 x 8,15 m

Total capacity of holds

4.583 m³ / 162.000 ft³

Hold ventilation

Electrical ventilation 6 air changes per hour basis empty hold

Hold is fitted with dehumidifier system

Number of hatches

1

54,60 x 10,30 m

Tank capacities

MGO: 173,2 m³

Water ballast: 1.982 m³

Fresh water: 26 m³

Manager

Wagenborg Shipping BV

Delfzijl

The Netherlands

Operator

Wagenborg Shipping B.V.

Owner

Lars en Angela But

Strandwal 67

4386 HG Vlissingen

The Netherlands

Registered owner

C.V. Scheepvaartonderneming But II

The Netherlands

Renamed

28/11/2022 Plataanborg

The Netherlands, Delfzijl - Call sign: PBRB

Registered owner: Wagenborg Shipowners 4 B.V.

Manager: Wagenborg Shipping B.V., Delfzijl - The Netherlands

Latest data adjustment

20 December 2023
