Westerschelde 03 September 2018 |
 |
 |
 |
||
| Westerschelde 03/09/18 | Spijkenisse 26 December 2020 | Westerschelde 28/03/20 | ||
|
Name |
MEREL V |
|
Type |
General Cargo - Single deck - Super Saimax - Strengthened for heavy cargoes |
|
IMO-number |
9279056 |
|
Call sign |
PHDK |
|
Flag |
The Netherlands |
|
Port of registry |
Hellevoetsluis |
|
GT |
2.409 t |
|
DWT |
3.250 t |
|
NT |
993 t |
|
Number of 20ft containers |
136 |
|
Length |
82,50 m overall 80,70 m between perpendiculars |
|
Breadth |
12,52 m extreme |
|
Draught |
5,34 m |
|
Air draft |
13,5 m |
|
Depth |
8,00 m moulded |
|
Speed |
11,8 knots |
|
Built |
2005 |
|
Keel laid |
2004 |
|
Delivery date |
15/06/2005 |
|
Builder casco |
Leda d.o.o. Domince bb HR 20260 Korcula Croatia |
|
Builder completion |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
1006 |
|
Hull material |
Steel |
|
Hull typre |
Double skinned |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar 3512 HD DITA - 4 stroke single acting 12 cylinder 170 x 190 mm combustion engine 1.250 kW / 1.699 bhp at 1.600 rpm Built: 2004 Manufacturer: Caterpillar Tractor Company Inc., Peoria (Illinois) - USA |
|
Gearbox |
1x Reduction gear Reintjes WAF-1172 - reduction 6.696:1 |
|
Propellers |
1x Controllable pitch propeller - aft at 239 rpm |
|
Shaft generator |
1x Stamford HCM-534 - 390 kVA |
|
Generators |
1x Sisu 634 DSBG - 6 cylinder 108 x 134 mm diesel engine 138 kW at 1.500 rpm connected with Stamford generator 150 kVA 1x Sisu 420 DSRG - 4 cylinder 108 x 120 mm diesel engine 70 kW at 1.500 rpm connected with Stamford generator 77 kVA Built 2004 Manufacturer: Sisu Diesel |
|
Bow thruster |
1x Veth-Jet Thruster 2-K-1000 - 220 kW electro-motor at 1.750 rpm |
|
Cargo capacity |
Grain: 4.583 m³ |
|
Number of holds |
1 54,60 x 10,30 x 8,15 m |
|
Hold ventilation |
6x Electrical ventilation air changes per hour basis empty hold Hold is fitted with dehumidifier system |
|
Number of hatches |
1 54,60 x 10,30 m |
|
Tank capacities |
MGO: 170 m³ Water ballast: 1.982 m³ Fresh water: 26 m³ |
|
Lifting equipment |
1x Gantry Crane |
|
Manager |
Wagenborg Shipping B.V. Delfzijl The Netherlands |
|
Operator |
Wagenborg Shipping B.V. |
|
Registered owner |
C.V. Scheepvaartonderneming Veltman II Delfzijl The Netherlands |
|
Renamed |
26/09/2023 Vlierborg The Netherlands, Delfzijl - Call sign: PHDK Owner & manager: Wagenborg Shipping B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
20 December 2023 |
