| Westerschelde 06 September 2016 |
|
Name |
FEDERAL SABLE |
|
Type |
Bulk carrier - Handysize |
|
IMO-number |
9595888 |
|
Call sign |
V7WS4 |
|
Flag |
Marshall islands |
|
Port of registry |
Majuro |
|
GRT |
24.196 t |
|
DWT |
Summer: 37.140 t Winter: 36.055 t |
|
NRT |
12.205 t Panama: 20.144 t Suez: 22.208 t |
|
Light ship |
9.801 t |
|
Length |
189,99 m overall 183,00 m between perpendiculars |
|
Breadth |
28,35 m extreme |
|
Draught |
Summer: 10,51 m Winter: 10,29 m |
|
Depth |
15,20 m moulded |
|
Speed |
14,0 knots laden |
|
Built |
2012 |
|
Keel laid |
24/12/2010 |
|
Date of completion |
06/01/2012 |
|
Builder |
Zhejiang Ouhua Shipbuilding Co., Ltd. Zhoushan China |
|
Yard number |
601 |
|
Hull material |
Steel - Part Higher Tensile Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6RTA48T - 2 cylinder 6 cylinder 480 x 2.000 mm combustion engine 5.250 kW / 7.138 hp at 116,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Number of holds |
5 Hold 1: 25,60 x 9,10 / 20,20 m Hold 2: 28,80 x 20,20 / 20,20 m Hold 3: 26,40 x 20,20 / 20,20 m Hold 4: 28,80 x 20,20 / 20,20 m Hold 5: 28,80 x 20,20 / 7,20 m |
|
Cargo hold capacity |
Grain / bale: Hold 1: 7.605 m³ / 7.400 m³ Hold 2: 10.575 m³ / 10.551 m³ Hold 3: 8.884 m³ / 9.683 m³ Hold 4: 10.575 m³ / 10.551 m³ Hold 5: 9.901 m³ / 9.746 m³ Total: 48.904 m³ / 47.931 m³ |
|
Hold ventilation |
Mechanical |
|
Number of hatches |
5 Hatch 1: 16,00 x 15,00 m Hatch 2: 22,40 x 18,00 m Hatch 3: 19,20 x 18,00 m Hatch 4: 22,40 x 18,00 m Hatch 5: 22,40 x 18,00 m |
|
Hatch cover type |
Folding hydraulic |
|
Max permitted loads |
Tanktop: 25,0 t/m² |
|
Tank capacities |
IFO: 1.261 m³ MDO: 400 m³ |
|
Cargo gear |
4x Electro hydraulic deck cranes – SWL 30,0 t each |
|
ISM manager |
Anglo Eastern Shipmanagement 17th Floor, Kingston International Centre, 19, Wang Chiu Road, Kowloon Bay, Kowloon Hong Kong - China |
|
Previous managers |
Fednav Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Registered owner |
Federal Cornwallis Ltd., 1st Floor, The Atrium Haggatt Hall, St. Michael, BB11063 - Barbados Care of Fednav Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Latest data adjustment |
14 May 2024 |
