| Brugge 15 February 2024 |
 |
|
| Br 15/02/24 | |
|
Name |
KAATA |
|
Previous names |
1999 - 2009 Catharina-C 2009 - 2020 Flex Emden |
|
Type |
Multi-purpose dry cargo - Equipped for carriage of containers Damen Combi Freighter 5000 |
|
IMO-number |
9184823 |
|
Call sign |
9HJX8 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
1999 - 2005 United Kingdom, Cowes - Call sign: MYDU8 2005 - 2009 Malta, Valletta 2009 - 2020 Antigua & Barbuda, St John’s - Call sign: V2EC2 |
|
GT |
2.999 t |
|
DWT |
Summer: 5.049 t Winter: 4.900 t |
|
NT |
1.714 t |
|
Displacement |
Summer: 6.512,8 t Winter: 6.366,2 t |
|
Lightship |
1.462,88 t |
|
Number of 20ft containers |
On deck: 104 In hold: 120 Total: 224 |
|
Container capacity 14t |
129 |
|
Length |
94,9 m overall 90,25 m between perpendiculars |
|
Breadth |
13,17 m overall |
|
Draught |
Summer: 6,20 m Winter: 6,07 m |
|
Depth |
7,15 m moulded |
|
Speed |
Service: 11,5 knots Max: 13,0 knots |
|
Built |
1999 |
|
Keel laid |
12/05/1998 |
|
Launch date |
09/12/1998 |
|
Date of completion |
01/05/1999 |
|
Builder casco |
Damen Shipyard Galati Galati Romania Yard number: 929 |
|
Builder completion |
B.V. Scheepswerf Damen Hoogezand The Netherlands Yard number: 731 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Movable bulkheads |
2x Movable, max 3 compartments |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.400 kW / 3.260 bhp at 750 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
2x Scania 6DS9 main Diesel generatorsets each 135 kW |
|
Emergency generator |
1x Valmet emergency/harbour generatorset 70 kVA |
|
Compressed air receivers |
2x Starting air compressor |
|
Bow thruster |
1x Fixed pitch thruster 300 kW, forward |
|
Number of holds |
1x Box-shaped hold 67,70 x 11,10 x8,40 m |
|
Cargo hold capacity |
Grain / Bale: 218.780 ft³ / 6.196 m³ |
|
Hold ventilation |
Electric driven 6 air-changes per hour |
|
Hatches |
1 67,70 x 11,10 m |
|
Hatch type |
10x Steel pontoon hatches with 1 gantry crane |
|
Tank capacities |
Ballast: 1.727,8 m³ IFO: 216 m³ MGO: 44 m³ FW: 41,4 m³ |
|
Crew |
9 |
|
Commercial manager |
Hansa Shipping Ltd Unit 111, Flat 7, Triq Santa Lucija Valletta, VLT 1183 Malta |
|
ISM manager |
Hansa Ship Management Ou Ahtri tn 12 10151 Tallinn Estonia |
|
Previous managers |
|
|
Registered owner |
HS Kaata OU Care of Hansa Shipping Ltd. Unit 111, Flat 7, Triq Santa Lucija Valletta, VLT 1183 Malta |
|
Previous names & owners |
|
|
Latest data adjustment |
17 February 2024 |
