| Westerschelde 06 June 2015 |
 |
|
| Westerschelde 06/06/15 | |
|
Name |
STAR KINN |
|
Previous names |
Build as: Star Kvarven |
|
Type |
Multi-purpose carrier - Container carriage |
|
IMO-number |
9396141 |
|
Call sign |
LAJF7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
37.158 t |
|
DWT |
49.850 t |
|
NT |
13.824 t |
|
Number of 20ft containers |
On hatch covers: 802 In holds: 618 Total: 1.420 |
|
Length |
208,77 m overall 197,40 m between perpendiculars |
|
Breadth |
32,25 m extreme |
|
Draught |
Summer: 12,36 m |
|
Freeboard |
7.160 mm |
|
Depth |
19,50 m |
|
Speed |
Full speed: loaded: 14,2 knots / ballast: 15,5 knots Eco speed: loaded: 12,2 knots / ballast: 13,2 knots |
|
Built |
2010 |
|
Keel laid |
10/06/2009 |
|
Launch date |
20/10/2009 |
|
Date of completion |
10/20/2010 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
8003 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Number of tweendecks |
4 |
|
Main engine |
Hyundai/MAN B&W/5S60MC-C - 2 stroke single actinf 5 cylinder combustion engine Mcr 11.900 kW ar 105,0 rpm |
|
Propellers |
1x Fixed pitch mono-block propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired - 7,0 bar 1x Auxiliary boiler, exhaust gas heated (Economizer) - 7,0 bar Builder: Kangrim Industries Co. Ltd. |
|
Generators |
2x Hyundai/Himsen 7H21/32 - 4 stroke 7 cylinder diesel engines each Mcr 1.440 kW connected with generatorsets each ouitput 1.350 kW 1x Hyundai/Himsen 5H21/32 - 4 stroke 5 cylinder diesel engine each Mcr 800 kW connected with generatorset each ouitput 750 kW |
|
Emergency generator |
1x Cummins NT/NTA855-M/-D(M) diesel generatorset |
|
Compressed air receivers |
2x Main air compressors: Sauer compressor-unit WP200 - 30,0 bar 1x Emergency air compressor: Sauer compressor Unit Type WP33L - 30,0 bar 1x Working air compressor: Atlas Copco compressor Type GA 37 VSD-175-6 - 7,5 bar |
|
Bow thruster |
1x 1.500 kW, forward 1x 750 kW, aft |
|
Number of holds |
11x Box-shaped cargo holds each 27,44 x 12,80 m |
|
Cargo hold capacity |
Hold 1: 4.435 m³ Hold 2: 6.545 m³ Hold 3: 6.713 m³ Hold 4: 6.713 m³ Hold 5: 6.713 m³ Hold 6: 6.713 m³ Hold 7: 6.713 m³ Hold 8: 6.713 m³ Hold 9: 6.545 m³ Hold 10: 5.553 m³ Hold 11: 1.849 m³ Total: 65.206 m³ |
|
Number of hatches |
11x Each 27,841 x 13,14 m |
|
Deck capacity |
Under deck: 5.362 m² Weather deck: 3.957 m² |
|
Max permitted loads |
Hatch covers: 3,0 t/m² Tweendecks: 5,5 t/m² Tantop # 2-8: 28,0 t/m² Tanktop: #9: 5,50 t/m² |
|
Tank capacities |
Ballast: 20.700,6 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Lifting equipment |
2x Provision cranes - SWL 4,0 t each 1x Engine r crane - SWL 4,0 t |
|
Cargo gear |
2x Gantry Cranes - SWL 70,0 t each |
|
Crew size |
32 |
|
Manager |
Grieg Star AS C Sundtsgate 17/19 5004 Bergen Norway |
|
Operator |
Grieg International II AS Bryggegata 6 0250 Oslo Norway |
|
Registered owner |
Salter Shipping, S.A No.20, Federico Boyd Avenue And 51st Street Panama City Republic Of Panama |
|
Renamed |
Star Kvarven |
|
Latest data adjustment |
20 October 2023 |
