Spar Lyra IMO 9289013 01
Westyerschelde 30 November 2018



Name

SPAR LYRA

Type

Bulk carrier - Strengthened for heavy cargo loading

Supramax

IMO-number

9289013

Call sign

LAZP5

Flag

Norway

Port of registry

Bergen

GT

32.474 t

DWT

53.565 t

NT

17.790 t

Length

190,00 m overall

Breadth

32,26 m moulded

Draught

Summer: 12,54 m

Moulded L x B x D

183,44 x 32,26 x 17,50 m

Keel to mast end

45,60 m

Freeboard

Summer: 4.986 mm

Depth

17,50 m moulded

Speed

14,0 knots

Built

2005

Keel laid

29/12/2003

Launch date

28/06/2004

Date of completion

14/01/2005

Builder

Chengxi Shipyard Co., Ltd.

Jiangsu

China

Yard number

CX4204

Hull material

Steel

Hull type

Double hull

Main engine

1x MAN-B&W 6s50mc-C - 2 Stroke 6 Cylinder 500 X 2.000 Mm Combustion Engine 9.480 Kw At 127,0 rpm

Manufacturer: Hudong Heavy Machinery Co., Ltd.

Propeller shaft

1x Oil lubrication shaft without monitoring device

Diameter: 469 mm

Propellers

1x Fixed Pitch Propeller

Boilers

1x Auxiliary vertical boiler - 0,90 MPa

Evaporation: 3,10 t/h

Manufacturer: Saacke Qingdao Marine Boiler Co.,Ltd.

Generators

4x Generatorsets total 2.706 kVA

Number of holds

5

Cargo hold capacity

Bale: 64.000 m³

Grain: 65.752 m³

Number of hatches

5

Tank capacities

Fuel oil: 2.004,0 m³

Fresh water: 239,0 m³

Cargo gear

4x Deck cranes - SWL 36,0 t each

Grabs: 4x Electro hydraulic

Commercial manager

Spar Shipping AS

Kokstadflaten 30

5257 Kokstad

Norway

ISM manager

Fleet Management Ltd.

27th Floor, South Island Place, 8, Wong Chuk Hang Road, Southern

Hong Kong

China

Registered owner

Spar Shipping AS

Kokstadflaten 30

5257 Kokstad

Norway

Latest data adjustment

14 July 2022
