Korsoe IMO 9519054 01

Westerschelde 20 June 2019



Name

KORSOE

Previous names

01/2013 - 12/2016 Delawarediep

Type

Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo

IMO-number

9519054

Call sign

5BTM3

Flag

Cyprus

Port of registry

Limassol

GT

4.358 t

DWT

Summer: 5.732 t

NT

2.525 t

Number of 20ft containers

In hold: 156

On deck: 105

Total: 261

Length

108,97 m overall

102,98 m between perpendiculars

Breadth

15,63 m

Draught

Summer: 5,88 m

Air draft

27,50 m ballast, masts collapsed

Depth

7,90 m moulded

Speed

12,4 knots

Built

2013

Keel laid

16/10/2008

Launch date

19/09/2012

Date of completion

13/01/2013

Builder

Rong Cheng Shipbuilding Industry Co., Ltd.

China

Yard number

RC27

Hull material

Steel

Movable bulkheads

2

Main engine

1x Yanmar 6EY26 - 4 stroke 6 cylinder 260 x 385 mm combustion engine 1.920 kW at 750 rpm

Propellers

1x Controllable pitch propeller

Shaft generator

1x 350 kW / 400 Volt, 50 Hz at 1.500 rpm

Generators

3x Deutz MWM TBD234V8 - 4 stroke 8 cylinder 128 x 140 mm diesel engines each Mcr 249 kW at 1.500 rpm connected with generators each 230 ekW / 400 Volt 50 Hz

Emergency generator

1x Deutz TBD234V6 diesel generatorset

Bow thruster

1x Kawasaki STT 170 TLK - 315 kW

Number of holds

2x With a full tween deck

Hold 1: 25,50 x 12,65 x 9,20 m

Hold 2: 45,75 x 12,65 x 9,20 m

Cargo hold capacity

Grain: 8.495 m³ / 303.694,9 ft³ excl? Bulkheads

Hold ventilation

6x Air changes per hour

Number of hatches

2

4 pontoons on hatch 1

7 pontoons on hatch 2

Max permitted loads

Tanktop: 15,00 t/m²

Hatchcover: 2,2 t/m²

Tweendeck: 2,4 t/m²

Tank capacities

HFO: 261,3 m³

MDO: 76,15 m³

Fresh water: 58,0 m³

Cargo gear

2x Deck cranes - SWL 45,0 each

Combinable to SWL 90,0

Crew size

8

Manager

Schulte & Bruns Chartering GmbH & Co KG

Hamburg

Germany

Previous names & owners

01/2013 - 12/2016 Delawarediep - Riverine Shipping Co Ltd.

Renamed

2021 Lapisland

Portugal, Madeira - Call sign: CQES4

Reg. owner: Lapisland Gmbh & Co KG - Germany

Manager: F&L Schifffahrt GmbH & Co KG - Germany

Latest data adjustment

17 September 2021
