Oshimana 01

Westerschelde 12 August 2019


Oshimana 03   Oshimana 04   Oshimana IMO 9249295 05   Oshimana IMO 9249295 06
Westerschelde 12/08/19 Westerschelde 12/08/19   Westerschelde 10/05/17   Westerschelde 07/08/19


Name

OSHIMANA

Previous names

07/2003 - 12/2007 Star Oshimana

Type

General cargo / Containership - Open hatch

IMO-number

9249295

Call sign

LAJR8

Flag

Norway

Port of registry

Bergen

Previous flags

2003 - 2020 Republic of Singapore, Singapore City - Call sign: 9VAH9

GT

36.324 t

DWT

50.470 t

NT

14.743 t

Number of 20ft containers

On Deck: 770

In holds: 628

Total: 1.398

Reefer capacity

22

Length

199,00 m overall

189,00 m between perpendiculars

Breadth

32,31 m extreme

32,26 m moulded

Draught

12,33 m

Depth

19,00 m

Speed

14,5 knots

Built

2003

Keel laid

10/01/2003

Launch date

21/05/2003

Date of completion

29/07/2003

Builder

Oshima Shipbuilding Co., Ltd.

Saikai

Japan

Yard number

10330

Hull material

Steel

Hull type

Single hull

Bulkheads

Transverse: 14

Main engine

1x Kawasaki/MAN-B&W 6S60MC - 2 stroke 6 cylinder 600 x 2.292 mm combustion engine 11.518 kW / 15.660 hp at 105,0 rpm

Builder: Kawasaki Heavy Industries

Propellers

1x Fixed pitch mono-block propeller

Manufacturer: Nakashima Propeller Co., Ltd.

Boilers

1x Auxiliary boiler, composite

Manufacturer: Aalborg Industries A/S

Generators

2x MAN-B&W 6L28/32H diesel generatorsets each 1.180 kW

1x MAN-B&W 5L28/32H diesel generatorset 1.000 kW

Emergency generator

1x Deutz BF6L913 diesel generatorset

Bow thruster

1x 1.500 kW / 2.000 hp, forward

1x 740 kW / 1.000 hp, aft

Number of holds

11

Cargo hold capacity

Hold 1: 4.852 m³ / 171.347 ft³

Hold 2: 6.332 m³ / 223.613 ft³

Hold 3: 6.498 m³ / 229.228 ft³

Hold 4: 6.498 m³ / 229.228 ft³

Hold 5: 6.498 m³ / 229.228 ft³

Hold 6: 6.498 m³ / 229.228 ft³

Hold 7: 6.498 m³ / 229.228 ft³

Hold 8: 6.498 m³ / 229.228 ft³

Hold 9: 6.498 m³ / 229.228 ft³

Hold 10:6.014 m³ / 2012/383 ft³

Hold 11: 2.703 m³ / 95.456 ft³

Total: 65.387 m³ / 2.307.395 ft³

Number of hatches

11

Tank capacities

Ballast: 16.180,2 m³

Anchor equipment

Length: 660,00 m

Diameter: 78 mm

Cargo gear

2x Travelling gantry cranes with full weather protection - SWL 68 t each

ISM & commercial manager

ZEABORN Ship Management (Singapore) Pte.

1 Maritime Square

#11-03 HarbourFront Centre

Singapore 099253

Republic of Singapore

Registered Owner

Masterbulk AS

Care of Masterbulk Ship Management Pte Ltd.

23-01, 79, Anson Road

Singapore 079906

Republic of Singapore

Latest data adjustment

05 November 2022
