Westerschelde 06 October 2015 |
 |
 |
|
| Westerschelde 06/10/15 | Westerschelde 10/10/19 |
|
Name |
SCHOKLAND |
|
Previous names |
Build as: Eems Ranger |
|
Type |
Multi-purpose general cargo ship - Strengthened for heavy cargoes - Open top - Tweendecker |
|
IMO-number |
9431599 |
|
Call sign |
PBWZ |
|
Flag |
The Netherlands |
|
Port of registry |
Urk |
|
GT |
2.702 t |
|
DWT |
Summer: 3.300 t |
|
DWCC |
Summer: 3.200 t Winter: 3.100 t |
|
NT |
1.386 |
|
Number of 20ft containers |
300 |
|
Length |
89,98 m overall 84,98 m between perpendiculars |
|
Breadth |
13,75 m |
|
Draught |
Max: 5,20 m |
|
Freeboard |
810 mm |
|
Depth |
6,26 m moulded |
|
Speed |
Service: 13,0 knots Max: 14,5 knots |
|
Built |
2010 |
|
Launch date |
04/08/2009 |
|
Delivery date |
08/07/2010 |
|
Builder |
Hong Ha Shipbuilding One Member Limited Liability Company HaiPhong Vietnam |
|
Yard number |
HH 07 |
|
Hull material |
Steel |
|
Watertight compartments |
44 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.980 kW / 2.690 hp at 750 rpm Manufacturer: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 215 rpm |
|
Shaft generator |
1x 468 kW / 585 kVA - 400 V 50 Hz |
|
Generators |
2x Main diesel generatorsets each 290 kVA - 232 kW - 340 HP / 400 V 50 Hz |
|
Bow thruster |
1x Tunnel thruster 240 kW / 326 bhp, forward |
|
Number of holds |
1 61,80 x 10,80 x 7,92 m |
|
Hold capacity |
Grain & bale: 4.870 m³ / 178.000 ft³ |
|
Number of hatches |
1 61,80 x 10,80 m |
|
Hatch type |
Pontoon |
|
Max permitted loads |
Tanktop: 15,0 t/m² Hatch cover:1,7 t/m² |
|
Tank capacities |
Fuel: 405,8 m³ |
|
Cargo gear |
Gearless |
|
Manager |
Amasus Shipping B.V. Abel Tasmanplein 4 9934 GD Delfzijl The Netherlands |
|
Registered owner |
Buter Shipping B.V. Lijkant 41 8321LK Urk The Netherlands |
|
Latest data adjustment |
07 August 2020 |
