Antwerpen 06 May 2020 |
 |
| Antwerpen 06/05/20 |
|
Name |
KELLY |
|
Previous names |
2004 launch as: Vermontborg 02/2004 - 10/2014 Winona 10/2014 - 2019 Lucina |
|
Type |
General cargo ship - Equipped for the carriage of containers |
|
IMO-number |
9255622 |
|
Call sign |
9HA4962 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2004 - 2014 Antigua & Barbuda, St. John's - Call sign: V2BQ7 2014 - 2014 Germany 2014 - 2019 Curaçao, Willemstad - Call sign: PJNG |
|
GT |
6.361 t |
|
DWT |
Summer: 9.857 t |
|
NT |
3.099 t |
|
Number of 20ft containers |
In hold: 264 On deck: 288 Total: 552 |
|
Reefer capacity |
50 |
|
Length |
132,23 m overall 123,84 m between perpendiculars |
|
Breadth |
15,87 m overall |
|
Draught |
Max: 7,75 m |
|
Depth |
11,15 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2004 |
|
Date of completion |
30/01/2004 |
|
Builder casco |
Deawoo-Mangalia Heavy Industries S.A. Mangalia Rumania |
|
Builder completion |
Bodewes Scheepswerf Volharding Foxhol B.V. Westerbroek The Netherlands |
|
Yard number |
515 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Partly double bottom |
|
Watertight compartments |
7 |
|
Movable bulkheads |
2x Moveable bulkheads, 8 store positions |
|
Continuous decks |
2 |
|
Main engine |
1x MaK 8M32L - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.217 bhp at 600 rpm Built: 2003 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 148 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 13,0 bar Heating surface: 17,5 m² 1x Thermal oil heater, exhaust gas heated - 13,0 bar Heating surface: 55,0 m² |
|
Electric installations |
2x Plant 440/220 V - 244 kVA 1x Plant 440 V - 813 kVA 1x Plant 440/220 V - 87 kVA |
|
Shaft generator |
1x 813 kVA - 650 kW |
|
Generators |
2x Main diesel generatorsets each 305 kVA - 244 kW - 374 hp |
|
Emergency generator |
1x Diesel generatorset 87 kVA - 70 kW - 109 hp |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster - 500 kW, forward |
|
Number of holds |
2 Hold 1: 39,96 x 13,20 x 10,89 m Hold 2: 52,54 x 13,20 x 10,89 m |
|
Cargo hold capacity |
Grain & bales: 12.813 m³ / 448.500 ft³ |
|
Number of hatches |
2 Hatch 1: 39,96 x 13,20 m Hatch 2: 52,54 x 13,20 m |
|
Hatch type |
Steel hatch covers pontoon type with handling crane |
|
Tank capacities |
Fuel oil: 465 m³ Water ballast: 3.718 m³ Freshwater: 70 m³ |
|
Anchor equipment |
3x Anchors weight each 3.300 kg Length: 495,00 m |
|
Crew size |
12 |
|
Manager |
Hansa Ship Management OU Ahtri 12 10151 Tallinn (Reval) Estonia |
|
Previous managers |
2004 - 2014 Intersee Schiffahrtsgesellschaft m.b.H. & Co K.G., Haren/Ems - German Federal Republic 2014 -2017 Transship Management C.V., Emmen - The Netherlands 2017 - 2018 Transship Management B.V., Groningen - The Netherlands 2018 - 2019 Wagenborg Shipping B.V., Delfzijl - The Netherlands |
|
Registered owner |
HS Kelly OU Tallinn (Reval) Estonia |
|
Previous names & owners |
2004 - 2014 Winona - Winona Schiffahrts G.m.b.H., Haren/Ems - Germany 2014 - 2017 Lucina - Frieda Shipping B.V. 2017 - 2018 Lucina - Transship Management B.V., Groningen - The Netherlands 2018 - 2019 Lucina - Transship Management C.V., Emmen - The Netherlands |
|
Latest data adjustment |
15 July 2020 |
