Westerschelde 04 March 2018 |
 |
 |
|
| Westerschelde 04/03/18 | Westerschelde 10/01/20 | |
|
Name |
ISOLDANA |
|
Previous names |
2000 - 2009 Star Isoldana |
|
Type |
General cargo / container ship with travelling gantry cranes with weather protection |
|
IMO-number |
9186235 |
|
Call sign |
LAJM8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
2000 - 2020 Republic of Singapore, Singapore City - Call sign: 9VVW |
|
GT |
33.448 t |
|
DWT |
44.691 t |
|
NT |
13.195 t |
|
Number of 20ft containers |
On hatch cover: 700 In hold: 1.396 Total: 2.096 |
|
Length |
198,50 m overall 189,50 m between perpendiculars |
|
Breadth |
31,03 m extreme |
|
Draught |
Max: 12,05 m |
|
Depth |
19,00 m |
|
Speed |
Max: 16,2 knots |
|
Built |
2000 |
|
Keel laid |
29/12/1999 |
|
Launch date |
01/04/2000 |
|
Date of completion |
20/07/2000 |
|
Builder |
Stocznia Szczecinska Nowa Sp. z o.o. Szczecin Poland |
|
Yard number |
B584-I/4 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Cegielski 6S60MC - 2 stroke 6 cylinder 600 x 2.292 mm combustion engine 11.200 kW / 15.228 bhp at 105,0 rpm manufacturer: Zakladi Przemyslu Metalowego H. Cegielski S.A., Poznan - Poleand |
|
Propellers |
1x Fixed pitch mono-bock propeller Builder: ABB Alstom Power UK Ltd. |
|
Boilers |
Auxiliary boiler, oil/gas fired Mission OS - 7,9 bar Auxiliary boiler, exhaust gas heated AQ 2 - 7,9 bar Builder: Aalborg Industries A/S |
|
Generators |
1x MAN-B&W 8L23/30 H main diesel generatorset 1.280 kW 2x MAN-B&W 6L23/30 H main diesel generatorsets each 960 kW |
|
Emergency generator |
1x MAN D 2866 TE diesel generatorset 192 kW Builder: MAN Nutzfahrzeuge AG |
|
Bow thruster |
1.500 kW, forward 750 kW, aft |
|
Number of holds |
11 |
|
Cargo hold capacity |
Hold 1: 3.972 m³ / 140.353 ft³ Hold 2: 5.780 m³ / 204.240 ft³ Hold 3: 6.155 m³ / 217.491 ft³ Hold 4: 6.155 m³ / 217.491 ft³ Hold 5: 6.155 m³ / 217.491 ft³ Hold 6: 6.155 m³ / 217.491 ft³ Hold 7: 6.155 m³ / 217.491 ft³ Hold 8: 6.155 m³ / 217.491 ft³ Hold 9: 6.155 m³ / 217.491 ft³ Hold 10: 5.780 m³ / 204.240 ft³ Hold 11: 2.735 m³ / 96.643 ft³ Total: 61.352 m³ / 2.167.913 ft³ |
|
Tank capacities |
Ballast: 16.512 m³ |
|
Cargo gear |
2x Cranes - SWL 70 t travelling gantry cranes with weather protection |
|
Crew size |
29 |
|
Commercial manager |
Saga Welco AS Tollbodgaten 22 3111 Tønsberg Norway |
|
ISM manager |
Westfal-Larsen Management AS Fabrikkgaten 6 5059 Bergen Norway |
|
Registered owner |
Masterbulk AS Fabrikkgaten 6 5059 Bergen Norway |
|
Latest data adjustment |
11 June 2024 |
