Westerschelde 06 August 2017 |
 |
| Westerschelde 06/08/17 |
|
Name |
GAS VENUS |
|
Type |
Liquefied gas carrier - LPG |
|
IMO-number |
9774197 |
|
Call sign |
3EKX |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
25.004 t |
|
DWT |
28.702 t |
|
NT |
7.501 t |
|
Length |
179,97 m overall |
|
Breadth |
28,40 m |
|
Draught |
10,42 m |
|
Reg. dimensions L x B x D |
172,94 x 28,40 x18,20 m |
|
Rule dimensions L x B x D |
169,69 x 28,40 x18,20 m |
|
Freeboard |
Summer: 3.600 mm |
|
Depth |
18,20 m |
|
Speed |
16,0 knots |
|
Built |
2017 |
|
Keel laid |
22.12.2015 |
|
Launch date |
10.03.2017 |
|
Date of completion |
22.06.2017 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. |
|
Yard number |
H8193 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 6 cylinder 500 x 2.500 mm diesel engine 8.480 kW at 97,4 rpm Date of manufacturer: 12.2016 Manufacturer: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Boiler CPB – 8,8 kg/cm² Heating surface: 318,00 m² Date of manufacturer: 10.2016 Manufacturer: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
3x Main diesel generatorsets 1.000 kVA / 450 Volt |
|
Cargo tank capacity |
38.611 m³ |
|
Tank capacities |
Fuel oil: 1.610,3 m³ Fresh water: 319,6 m³ Water ballast: 12.636,8 m³ |
|
Manager |
KSS Line Ltd. |
|
Registered owner |
Kttwo Shipping S.A. |
|
Latest data adjustment |
03 September 2017 |
