Westerschelde 11 November 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/12/18 | Westerschelde 30/12/18 | Westerschelde 13/04/15 | Antwerpen 22/05/15 | Westerschelde 04/10/20 | Westerschelde 09/03/19 | |||||
 |
||||||||||
| Westerschelde 30/12/18 | ||||||||||
|
Name |
HAPPY PENGUIN |
|
Type |
Liquefied gas tanker - Ethylene carrier |
|
IMO-number |
9623996 |
|
Call sign |
2GBB2 |
|
Flag |
Isle of Man - United Kingdom |
|
Port of registry |
Douglas |
|
GRT |
8.009 t |
|
DWT |
Summer: 8.643 t |
|
NT |
2.403 t |
|
Length |
113,00 m overall 106,27 m between perpendiculars |
|
Breadth |
19,20 m moulded |
|
Draught |
8,45 m |
|
Keel to mast end |
38,57 m |
|
Depth |
10,60 m moulded |
|
Speed |
15,5 knots |
|
Built |
2013 |
|
Keel laid |
22/08/2012 |
|
Launch date |
15/12/2012 |
|
Date of completion |
03/06/2013 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. (Busan Shipyard) Pusan South Korea |
|
Yard number |
B-5063 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W/STX 6S35ME-B9.1 - 6 cylinder 350 x 1.550 mm combustion engine 5.005 kW / 6.805 hp at 167 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite (composite boiler) Builder: Kangrim |
|
Generators |
3x MAN Holeby 6L23/30H diesel generatorsets each 960 kW Builder: MAN Diesel & Turbo SE |
|
Emergency generator |
1x Cummins diesel generatorset |
|
Bow thruster |
1x KTE-Nakashima controllable pitch propeller 542 kW |
|
Number of tanks |
2 + 1 deck tank |
|
Tank capacity |
Tank 1: 2.792,26 m³ Tank 2: 1.994,27 m³ Tank 3: 1.993,51 m³ Total: 6.780,04 m³ |
|
Number of pumps |
3x Svanehoy cargo pumps each 325 m³/h |
|
Min temp |
-104°C |
|
Pressure |
5,5 bar |
|
Ballast capacity |
3.415,1 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 50 mm |
|
Lifting equipment |
1x Crane -SWL 4,0 t |
|
Commercial manager |
Unigas International B.V. Grotiushuis, 6th floor Westblaak 41 3012 KD Rotterdam The Netherlands |
|
ISM manager |
Ultraship ApS Smakkedalen 6 2820 Gentofte Denmark |
|
Owner |
Zelandia Shipping Company S.A. Care of Unigas International Grotiushuis, 6th floor Westblaak 41 3012 KD Rotterdam The Netherlands |
|
Latest data adjustment |
08 September 2022 |
