Name |
HAPPY BRIDE |
|
Previous names |
1999 - 2002 Tarquin Loch |
|
Type |
Liquefied gas tanker |
|
IMO-number |
9181900 |
|
Call sign |
9HA3975 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
Until 2015 Isle of Man - United Kingdom, Douglas - Call sign: ZIRQ8 |
|
GT |
4.693 t |
|
DWT |
Summer: 5.994 t |
|
NT |
1.754 t |
|
Length |
106,30 m overall 99,29 m between perpendiculars |
|
Breadth |
15,76 m |
|
Draught |
6,29 m |
|
Freeboard |
1.020 mm |
|
Depth |
8,25 m |
|
Speed |
15,0 knots |
|
Built |
1999 |
|
Date of completion |
07.05.1999 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. |
|
Yard number |
1146 |
|
Hull material |
Steel |
|
Hull type |
Double side |
|
Watertight compartments |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W - 2 stroke 5 cylinder 250 x 1.400 mm diesel engine - 3.500 kW / 4.755 hp at 170 rpm Built: 1998 Builder: Hyundai, Ulsan - South Korea |
|
Propellers |
1x Screw propeller controllable pitch at 170 rpm |
|
Boilers |
1x CHM 22,00 m² - 13,0 bar |
|
Electrical installation |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Shaft generators |
1x 500 kVA - 400 kW |
|
Generator |
4x Main diesel generatorsets each 472 kVA - 378 kW - 604 hp |
|
Number of tanks |
2 |
|
Total capacity of tanks |
3.204 m³ |
|
Minimum temperature |
-48°C |
|
Cargo handling |
2x Pumps each 700 m³/h |
|
Fuel capacity |
731 m³ |
|
Crew |
15 |
|
Manager |
BSM - Bernhard Schulte Shipmanagement Ltd. |
|
Operator |
Unigas Grotiushuis, 6th floor |
|
Owner |
Highland Shipping Co. |
|
Registered owner |
First Steamship S.A. |
|
Latest data adjustment |
27 January 2017 |
