Navigator Luga IMO 9761164 01
Westerschelde 20 April 2019



Name

NAVIGATOR LUGA

Type

Liquefied gas tanker - LPG

IMO-number

9761164

Call sign

D5KV9

Flag

Liberia

Port of registry

Monrovia

GT

18.219 t

DWT

19.002 t

NT

5.465 t

Length

159,89 m overall

152,20 m between perpendiculars

Breadth

25,64 m extreme

Draught

Summer: 9,52 m

Keel to mast end

45,40 m

Depth

16,40 m

Speed

Service: 15,0 knots

Max: 17,4 knots

Built

2017

Keel laid

22/12/2015

Launch date

19/10/2016

Date of completion

24/01/2017

Builder

Hyundai Mipo Dockyard Co., Ltd.

Ulsan

South Korea

Yard number

8194

Hull material

Steel

Hull type

Double bottom

Continuous decks

1

Main engine

1x MAN-B&W/Hyundai 6S50ME-C8 - 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine Mcr 7.410 kW / 10.075 hp at 114,0 rpm

Builder: Hyundai Heavy Industries Co Ltd - South Korea

Propellers

1x Fixed pitch mono-block propeller - aft at 114,0 rpm

Boilers

1x Auxiliary boiler, oil/gas fired

1x Auxiliary boiler, exhaust gas heated (Economizer)

Generators

3x Hyundai Himsen 6H21/32 - 4 stroke 6 cylinder 210 x 320 mm diesel engines each Mcr 850 kW connected with generators each 800 kW / 450 Volt 60 Hz

Builder: Hyundai Heavy Industries Co., Ltd.

Emergency generator

1x Doosan ADO86T1 diesel generatorset

Cargo tank capacity

Liquid: 22.149 m³

Number of pumps

6x Cargo pumps each 350 m³/h

Tank capacities

Ballast: 9.349,1 m³

Anchor equipment

Length: 605,00 m

Diameter: 62 mm

Crew size

16

Commercial manager

Navigator Gas LLC

The Verde, 10, Bressenden Place

London, SW1E 5DH

United Kingdom

Manager

Northern Marine Management Ltd.

Alba House, 2, Central Avenue, Clydebank Business Park,

Clydebank, G81 2QR

United Kingdom

Registered owner

Navigator Luga LLC

Care of Navigator Gas LLC

The Verde, 10, Bressenden Place

London, SW1E 5DH

United Kingdom

Latest data adjustment

27 April 2022
