Westerschelde 12 July 2019 |
 |
|
| Westerschelde 22/09/17 | |
|
Name |
EXCALIBUR |
|
Type |
Liquefied gas tanker - Ethylene gas - LPG |
|
IMO-number |
9480409 |
|
Call sign |
IBAP |
|
Flag |
Italy |
|
Port of registry |
Ravenna |
|
GT |
4.744 t |
|
DWT |
Summer: 5.312 t |
|
NT |
1.423 t |
|
Displacement |
Light ship: 2.960 t Load summer: 8.355 t |
|
Length |
103,90 m overall 97,20 m between perpendiculars |
|
Breadth |
16,40 m |
|
Draught |
Summer: 7,20 m |
|
keel to top antenna |
33,50 m |
|
Air draft |
27,50 m normal ballast |
|
Depth |
8,40 m moulded |
|
Speed |
Service: 16,0 knots |
|
Built |
2012 |
|
Launch date |
28/10/2009 |
|
Date of completion |
04/04/2012 |
|
Builder |
Bach Dang Shipyard Co., Ltd. Haiphong Vietnam |
|
Yard number |
EG4500-BD03 |
|
Hull material |
Steel |
|
Number of decks |
1 |
|
Main engine |
1x Wärtsilä 8L32 - 4 stroke single acting 8 cylinder combustion engine MCR 5.364 bhp / 4.000 kW at 750 kW CSR 3.400 kW |
|
Propellers |
1x Variable pitch / Becker type |
|
Shaft generator |
1x Marelli (Wärtsilä) 1.200 ekW |
|
Generators |
4x Volvo Penta D16 diesel generatorsets each 470 ekW |
|
Emergency generator |
1x Diesel generatorset 90 kW |
|
Bow thruster |
400 kW / 500 hp |
|
Number of cargo tanks |
2 |
|
Cargo tank capacity |
100% Tank 1: 2.168,1 m³ Tank 2: 2.390,2 m1 Total: 4.558,3 m³ 98% Tank 1: 2.124,8 m³ Tank 2: 2.342,4 m³ Total: 4.467,2 m³ |
|
Max discharging rate |
700 m³/h |
|
Pumps |
2x Garbarino type MU150-315LE Deepwell submerged electric centrifugal cargo pumps each 460 m³/h 1x Buster pump 1x 400 m³/h |
|
Max pressure |
8,0 bar |
|
Min temp |
-104°C |
|
Manifolds |
Distance bow to mid-point manifold: 58,30 m Distance stern to mid-point manifold: 47,50 m |
|
Tank capacities |
Fuel oil: 440,99 m³ Gas oil: 123,48 m³ Fresh water 124,20 m³ |
|
Lifting equipment |
1x Cargo hose crane - SWL 5,0 t 1x Service crane - SWL 2,0 t |
|
Manager |
Gasmare Synergy S.r.l., Saronno - Italy |
|
Previous manager |
04/2012 - 2017 Societa Mediterranea di Navigazione S.p.A., Ravenna - Italy |
|
Registered owner |
Mediterranea Di Navigazione S.P.A. Piazza Caduti sul lavoro 3 48122 Ravenna Italy |
|
Renamed |
12/2020 Coral Siderea The Netherlands, Rotterdam - Call sign PDWH Reg. owner: Coral Siderea Shipping BV - the Netherlands Manager: Anthony Veder Rederijzaken B.V., Rotterdam, The Netherlands |
|
Latest data adjustment |
13 February 2021 |
