Westerschelde 05 July 2016 |
 |
| Westerschelde 22/03/16 |
|
Name |
MNO ZEEZAND |
|
Type |
Trailing suction hopper dredger |
|
IMO-number |
9196278 |
|
ENI-number |
02719417 |
|
Call sign |
PCHT |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
1.445 t |
|
DWT |
Summer: 2.177 t |
|
NT |
437 t |
|
Length |
82,00 m overall 77,30 m between perpendiculars |
|
Breadth |
11,50 m |
|
Draught |
4,29 m |
|
Freeboard |
1.180 mm |
|
Depth |
5,10 m |
|
Speed |
11,0 knots |
|
Built |
1999 |
|
Date of completion |
21/12/1999 |
|
Builder |
Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
292 |
|
Hull material |
Steel |
|
Watertight compartments |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar 3516 DITA- 4 stroke 16 cylinder 170 x 215 mm combustion engine 1.259 kW / 1.711 hp at 1.600 rpm Built: 1999 Builder: Caterpillar Inc., Lafayette (Indiana) - USA |
|
Propellers |
1x Screw propeller controllable pitch - aft at 233 rpm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Generators |
1x Main diesel generatorset 106 kVA - 85 kW - 129 hp |
|
Emergency generator |
1x Diesel generatorset 45 kVA - 36 kW - 56 hp |
|
Number of holds |
2 |
|
Hopper capacity |
1.605 m³ |
|
Suction pipe |
1x 650 mm |
|
Dredging depth |
30,00 m |
|
Manager |
Spaansen Grondstoffen en Logistiek BV Lange Lijnbaan 60 8861 NW Harlingen The Netherlands |
|
Owner |
Spaansen Zeevaart B.V. The Netherlands |
|
Registered owner |
Spaansen Holding B.V. The Netherlands |
|
Latest data adjustment |
01 October 2020 |
