| Zeebrugge 06 May 2013 |
 |
 |
|
| Zeebrugge 20/04/13 | Zeebrugge 20/04/13 | |
|
Name |
MORAG M |
|
Type |
Multi Purpose workboat - Eurocarrier 22 |
|
IMO-number |
9546849 |
|
Call sign |
2CQO5 |
|
Flag |
United Kingdom |
|
Port of registry |
Greenock |
|
GT |
135 t |
|
DWT |
130 t |
|
NT |
91,87 t |
|
Length |
21,60 m overall 21,50 m between perpendiculars |
|
Breadth |
9,04 m |
|
Draught |
Summer: 2,70 m Draft dry: 1,80 m Draft loaded: 3,00 m |
|
Speed |
10,0 knots cruising |
|
Built |
2009 |
|
Date of completion |
09.01.2009 |
|
Builder |
Neptune Marine Service BV |
|
Yard number |
337 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Caterpillar C18 - 4 stroke 6 cylinder 145 x 183 mm diesel engines each 447 kW / 600 hp at 1.800 rpm Builder: Caterpillar tractor company, Mossville-Illenois - USA |
|
Gearboxes |
2x 4.59.1 twin disk MG5222 Hydraulic power pack |
|
Propellers |
2x Screw propeller solid |
|
Electric installations |
220 Volt AC supply to UK sockets 24 Volt supply 110 Volt supply on deck |
|
Generators |
1x John Deere diesel generatorset 120 KVA / 69 kW closed cooling 1x John Deere diesel generatorset 120 KVA / 75 kW radiator cooled |
|
Bollard pull |
16 t |
|
Towing hook |
30 t quick release |
|
Deck load |
73 t |
|
Deck area |
150 m² |
|
Winches |
50 t Anchor handling winch with split drum 10 t Bridge controlled tugger winch Crane mounted winch |
|
Fuel capacity |
35 m³ |
|
Lifting equipment |
1x Heila Model HLRM 140-3SL - Remote control crane 18,6 t at 7,53 m 13,5 t at 9,70 m 10,3 t at 11,87 m 8,00 t at 14,04 m 1x Boom mounted winch - SWL 5,0 t |
|
Crew |
4 |
|
Passengers |
12 |
|
Main office |
Rhu Marina, Rhu Argyll & Bute G84 8LH Scotland United Kingdom |
|
Registered owner |
Gareloch Support Services (Plant) Ltd. |
|
Last update |
22.05.2013 |
