Magraret Ann - ENI 02103821

Name

MAGRARET ANN

Previous names

1964 - 1979 Sexta II

1979 - 1980 Aletta

Type

Suction hopper dredger

ENI-number

02103821

Call sign

PG 8169

Flag

The Netherlands

Port of registry

Sas Van Gent

GT

1.248 t

Length

85,90 m

Breadth

8,54 m

Draught

Summer: 3,01 m

0,76 m empty

Depth

3,27 m

Speed

10,0 knots

Built

1964

Rebuild: 1996

Builder

Piet Hein NV

Papendrecht

The Netherlands

Yard number

711

Hull material

Steel

Main engine

1x Caterpillar 3412 TA combustion engine out put 500 kW / 680 hp

Propellers

1

Generators

1x Generatorset: 90 kVA

1x Generatorset: 42,5 kVA

Harbour generator: 28 kVA

Bow thruster

1x DAF diesel output 199 kW

Hopper capacity

834 m³

Dredging system

• Dredging pump: Pettibone

• Capacity: 2.400 m³/h

• Suction pipe: diameter: 450 mm

• Dredging depth: 14,00 m

• Dredging pump drive: Caterpillar 625 kW

• Jet pump: Nijhuis - Capacity: 900 m³/h at 8 bar

• Jet pump drive: Caterpillar diesel 293 kW

Tank capacities

Fuel oil: 22,2 m³

Ballast water: 50,0 m³

Fresh water: 6,0 m³

Accommodation

For 4 persons

Operator

DC Group - De Cloedt NV

Owner

Margaret Ann BV

Wervenweg 14-15

4551 MC Sas van Gent

The Netherlands

Previous names & owners

1964 - 1975 Sexta II - W. van den Graaf, Dordrecht - The Netherlands

1975 - 1979 Sexta II - M. Gasten, Dordrecht - The Netherlands

1979 - 1980 Aletta - A. van der Zwaag, Venhuizen - The Netherlands

1980 - 1992 Margaret Ann - G.B. Versloot BV, Sint Jansteen - The Netherlands

Latest data adjustment

31 May 2023
