| Westerszchelde 07 February 2018 |
 |
 |
 |
 |
|||
| Antwerpen 07/04/09 | Zeebrugge 24/07/12 | Zeebrugge 04/05/14 | Zeebrugge 04/05/14 | |||
|
Name |
MSC BEATRICE |
|
Type |
Cellular containership |
|
IMO-number |
9399014 |
|
Call sign |
3FUF2 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
151.559 t |
|
DWT |
156.085 t |
|
NT |
83.151 t |
|
Number of 20ft containers |
13.798 t |
|
Container capacity 14t |
10.500 t |
|
Reefer point |
1.000 |
|
Length |
366,07 m overall 351,60 m registered |
|
Breadth |
51,20 m registered |
|
Draught |
15,60 m |
|
Forecastle |
175,04 m |
|
Bridge |
164,84 m |
|
Poop |
20,02 m |
|
Freeboard |
4.838 mm |
|
Depth |
29,90 m moulded |
|
Speed |
Max.: 24,1 knots |
|
Built |
2009 |
|
Keel laid |
16/10/2008 |
|
Launch date |
23/12/2008 |
|
Date of completion |
04/03/2009 |
|
Builder |
Samsung Heavy Industries Co., Ltd. Geoje Shipyard 530, Jangpyeong-ri, Sinhyeon-eup Geoje , Gyeongsangnam-do 656-710 Republic of Korea |
|
Yard number |
1709 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 12K98MC-C Mk7 - 2 stroke single acting 12 cylinder 980 x 2.400 mm combustion engine 72.240 kW / 98.219 hp at 104,0 rpm Year of manufacture: 2008 Manufacturer: Doosan Engine Co., Ltd. 69-3, Sinchon-dong Changwon , Gyeongnam 642-370 Republic of Korea |
|
Propeller |
Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,81 bar Heating surface: 76,0 m² 1x Steam boiler, exhaust gas heated - 9,81 bar Heating surface: 1.204 m² Year of manufacture; 2008 Manufacturer: KangRim Ind. Co., Ltd. (3rd Factory) 40, Wongnam-dong Changwon Republic of Korea |
|
Electric installations |
1x Plant 6600 V - 4.225 kVA 1x Plant 6600 V - 4.225 kVA 1x Plant 6600 V - 4.225 kVA 1x Plant 6600 V - 4.225 kVA 1x Plant 450 V - 625 kVA 3x Plants each 24 V - 36 Ah 1x Plant 24 V - 92 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 215 Ah 2x Plants each 110 V - 360 Ah |
|
Generators |
4x MAN-B&W 7L32/40 main diesel generatorsets each 3.380 kW / 4.225 kVA |
|
Emergency generator |
1x Diesel generatorset 625 kVA |
|
Batteries |
2x Batteries for automation each 360 Ah 1x Battery for start emergency engine 215 Ah 1x Battery for UPS radio 200 Ah 1x Battery for UPS navigation 200 Ah 1x Battery for automation 92 Ah 3x Batteries for automation each 36 Ah |
|
Compressed air receivers |
2x Receivers each 16.500 litres - 30,0 bar 1x Receiver 300 litres - 30,0 bar 1x Receiver 250 litres - 7,0 bar |
|
Bow thruster |
2x Transverse thruster each 1700 kW forward |
|
Anchor equipment |
3x Anchors weight each 24.500 kg Chain length: 770,00 m |
|
Cargo gear |
None |
|
Crew size |
34 |
|
Manager |
MSC Mediterranean Shipping Company S.r.l. Via Francesco Ciampa, 29 80063 Piano di Sorrento (NA) Italy |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Owner |
Compania Naviera Beatrice S.A. WTC, Calle 50 No. 102 Edificio Universal No. 50 Planta Baja No. 6 Panama City Republic of Panama |
|
Latest data adjustment |
25 February 2024 |
