Westerschelde 12 June 2019 |
 |
 |
 |
 |
|||
| Westerschelde 21/02/20 | Westerschelde 01/11/18 | Westerschelde 02/10/19 | Westerschelde 02/10/19 | |||
|
Name |
YM ESSENCE |
|
Type |
Cellular containership - Carriage of dangerous goods - Panamax |
|
IMO-number |
9496599 |
|
Call sign |
BLHO |
|
Flag |
Taiwan |
|
Port of registry |
Keelung |
|
GT |
47.952 t registered |
|
DWT |
Summer: 57.320 t |
|
NT |
20.411 t registered |
|
Displacement |
76.537 t |
|
Number of 20ft containers |
4.662 |
|
Container capacity 14t |
3.450 |
|
Reefer capacity |
400 |
|
Length |
259,00 m overall 246,40 m between perpendiculars |
|
Breadth |
37,30 m moulded |
|
Draught |
Max: 12,80 m |
|
Freeboard |
6.650 mm |
|
Depth |
19,40 m moulded |
|
Speed |
Max: 23,7 knots |
|
Built |
2014 |
|
Keel laid |
16/10/2013 |
|
Launch date |
15/03/2014 |
|
Delivery date |
01/07/2014 |
|
Builder |
CSBC Corporation, Taiwan |
|
Yard number |
965 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsui MAN-B&W 7K98ME6.1 - 2 stroke single acting 7 Cylinder 980 x 2.660 mm combustion engine 35.140 kW / 47.776 hp at 90 rpm Manufacturer: Mitsui Engr. & Shipbuilding Co. Ltd. |
|
Propellers |
1x Fixed pitch propeller - aft at 90 rpm Manufacturer: Mecklenburger Metallguss GmbH |
|
Boilers |
1x Fired boiler - 8,0 bar 1x Unfired exhaust gas boiler - 12,0 bar Manufacturer: Alfa Laval Qingdao Ltd. |
|
Main generators |
3x Daihatsu 8DK-28e - 4 stroke 8 cylinder 208 x 390 combustion engines each 2.530 kW at 720 rpm coupled with 3 generators 2.380 kW each Engine builder: Daihatsu Diesel Mfg. Co. Ltd. Generator builder: Nishishiba Electric Co., Ltd. |
|
Bow thruster |
1x Tunnel thruster 1.725 kW / 2.345 bhp, forward |
|
Tank capacities |
Fuel oil: 4.597,20 m³ Lub oil: 2,68 m³ Ballast: 16.405,30 m³ Fresh water: 633,60 m³ Diesel oil: 1.080,20 m³ |
|
Lifting equipment |
2x Suez mooring boat/Fuel oil hose handling davit - SWL 4,0 t each 1x port side 1x starboard Manufacturer: Unicrane Machinery Co., Ltd. |
|
Cargo gear |
Gearless |
|
Crew size |
30 |
|
Crew |
22 |
|
Operator |
Yang Ming Marine Transport Corporation 271, Mingde 1st Road, Qidu District Keelung City, 20646 China, Republic of (Taiwan) |
|
Owner |
965 |
|
Registered owner |
All Oceans Transportation Inc. |
|
Latest data adjustment |
22 July 2020 |
