Westerschelde 17 July 2015 |
 |
 |
|
| Antwerpen 29/07/19 | Westerschemde 21/05/15 | |
|
Name |
ORCA I |
|
Previous names |
2006 - 05/2014 CMA CGM Orca |
|
Type |
Cellular containership |
|
IMO-number |
9318113 |
|
Call sign |
3FPD6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
2006 - 2011 United Kingdom - Call sign: MPQF5 |
|
GT |
54.309 t |
|
DWT |
Summer: 65.954 t |
|
NT |
34.011 t |
|
Number of 20ft containers |
5.078 |
|
Container capacity 14t |
3.320 |
|
Reefer capacity |
550 |
|
Length |
294,12 m overall 278,73 m between perpendiculars |
|
Breadth |
32,20 m |
|
Draught |
Max: 13,52 m |
|
Freeboard |
3.867 mm |
|
Depth |
21,80 m |
|
Speed |
Max: 26,6 knots |
|
Built |
2006 |
|
Date of completion |
06/11/2006 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Mokpo South Korea |
|
Yard number |
279 |
|
Hull material |
Steel |
|
Watertight compartments |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x Hyundai/MAN-B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm combustion engine 57.076 kW / 77.549 hp at 104,0 rpm Built: 2006 Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x CHR Aalborg 390,00 m² - 9,0 bar 1x CHO Aalborg 40,14 m² - 10,0 bar |
|
Electric installations |
Power voltage: 450 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
3x Main diesel generatorsets each 3.000 kVA - 2.400 kW - 3.465 hp |
|
Emergency generator |
1x Diesel generatorset 250 kVA - 200 kW - 345 hp |
|
Bow thruster |
1x 1.800 kW |
|
Number of holds |
6 |
|
Tank capacities |
Fuel: 8.881,6 m³ |
|
Cargo gear |
Gearless |
|
Commercial manager |
Conchart Commercial Inc. 3-5, Menandrou Street, Kifisia 145 61 Athens Greece |
|
ISM Manager |
Technomar Shipping Inc. 3-5, Menandrou Street, Kifisia 145 61 Athens Greece |
|
Registered owner |
Zeus One Marine LLC C/o Conchart Commercial Inc. 3-5, Menandrou Street, Kifisia 145 61 Athens Greece |
|
Latest data adjustment |
21 January 2020 |
